Recent activity

The geomagnetic field was quiet on February 5. Solar wind speed ranged between 316 and 355 km/s.

Solar flux measured at 20h UTC on 2.8 GHz was 77.8. The planetary A index was 3 (STAR Ap - based on the mean of three hour interval ap indices: 3.0). Three hour interval K indices: 00001211 (planetary), 00101111 (Boulder).

The background x-ray flux is at the class A6 level.

At midnight there were 3 spotted regions on the visible solar disk.

Region 11043 decayed slowly and quietly.

Spotted regions not numbered by NOAA/SWPC:
[S749] This region emerged late in the day in the northern hemisphere near the central meridian. Location at midnight: N19E02.
[S750] The region emerged quickly late in the day in the northeast quadrant. The initial magnetic field configuration is complex and the region has a high potential for further development. C flares are possible. Location at midnight: N22E26.

Coronal mass ejections (CMEs)

February 3-5: No obvious partially or fully Earth directed CMEs were observed in LASCO or STEREO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent coronal hole (CH390) in the northern hemisphere will rotate into an Earth facing position on February 6-7.

Processed SOHO/EIT 195 image at 00:48 UTC on February 6. The darkest areas on the solar disk are likely coronal holes.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is good. Propagation on long distance northeast-southwest paths is poor.

Forecast

The geomagnetic field is expected to be mostly quiet on February 6-9. A high speed stream from CH390 could cause unsettled to active conditions on February 10.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)



1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered SWPC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
11043 2010.01.30 1 1 N24W50 0020 HAX classification was HSX at midnight
11044 2010.02.05 1   N18W36 0010 AXX spotless at midnight
S749 2010.02.05   2 N19E02 0010 BXO
S750 2010.02.05   4 N22E26 0020 BXO
Total spot count: 2 7
SSN: 22 37

Monthly solar cycle data

Month Average measured solar flux International sunspot number (SIDC) Smoothed sunspot number Average Ap
(3)
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.

2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2008.07 65.7 0.5 2.8 (-0.4)
2008.12 69.2 0.8 1.7 (-)
sunspot minimum
3.25
2009.01 69.8 1.3 1.8 (+0.1) 3.70
2009.02 70.0 1.4 1.9 (+0.1) 4.68
2009.03 69.2 0.7 2.0 (+0.1) 4.85
2009.04 69.7 1.2 2.2 (+0.2) 4.52
2009.05 70.5 2.9 2.3 (+0.1) 4.75
2009.06 68.6 2.6 2.7 (+0.4) 5.22
2009.07 68.2 3.5 3.6 (+0.9) 5.49
2009.08 67.3 0.0 (4.5 predicted, +0.9) 5.70
2009.09 70.5 4.2 (5.5 predicted, +1.0) 3.88
2009.10 72.6 4.6 (6.6 predicted, +1.1) 3.66
2009.11 73.6 4.2 (7.8 predicted, +1.2) 2.45
2009.12 76.7 10.6 (9.2 predicted, +1.4) 1.41 / 1.92
2010.01 81.1 13.1 (11.0 predicted, +1.8) 2.93
2010.02 75.3 (1) 2.5 (2) (13.0 predicted, +2.0) (5.9)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SWPC) sunspot number. The official international sunspot number is typically 30-50% lower.
3) Running average based on the daily SWPC ap indices. Values in red are based on official NGDC records.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
