The geomagnetic field was quiet to major storm on June 4. Solar wind speed ranged between 331 and 553 km/s. A moderately strong solar wind shock was observed at SOHO at 19:45 UTC. This was the arrival of the CME observed on June 1.
Solar flux measured at 20h UTC on 2.8 GHz was 102.8 (increasing 0.6 over the last solar rotation). The planetary A index was 15 (STAR Ap - based on the mean of three hour interval ap indices: 15.3). Three hour interval K indices: 01100156 (planetary), 02101245 (Boulder).
The background x-ray flux is at the class B2 level.
At midnight UTC the visible solar disk had 8 spotted regions.
Region 11225 decayed slowly and quietly.
Region 11226 decayed losing spots and penumbral area.
Region 11227 was quiet and stable.
Region 11228 was quiet and stable.
Region 11229 decayed slowly and could soon become spotless.
Region 11232 was quiet and stable.
Spotted regions not numbered by NOAA/SWPC:
[S1044] was split off from region 11227 on June 1. The region is
decaying and lost penumbra on the leader spots. Location at midnight: S19W16.
[S1047] emerged in the southeast quadrant on June 4. Location at midnight:
S26E52
June 2: A slow, faint full halo CME was observed in association with the C3
event at 07:46 UTC to the north of region S1044.
June 3-4: No earth directed CMEs were observed.
Coronal hole history (since late October
2002)
Compare today's report to the situation one solar rotation ago:
28 days ago
27 days
ago 26
days ago
A poorly defined weak coronal area or coronal hole (CH453) across the equator between regions S1044 and 11228 was Earth facing on June 4.
The above coronal hole map is based on a new method where coronal holes are detected automatically. The method may need some fine tuning, however, it has significant advantages over detecting coronal holes manually. The main improvement is the ability to detect coronal holes at and just beyond the solar limbs. Early results using this method for SDO images over a span of several weeks indicate a good match between coronal holes observed over the visible disk and their extent and position at the east and west limbs. Note that the polar coronal holes are easily detected using the new method, the extent and intensity of both holes are consistent with other data sources.
Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is poor to fair.
The geomagnetic field is expected to be unsettled to major storm on June 5 with a chance of severe storm intervals and quiet to active on June 6 due to CME effects. On June 7 effects from CH453 could arrive and cause some unsettled intervals with a chance of active intervals.
| Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth within the
next 5 days. When the high speed stream has arrived the color changes to
green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48
hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
(Click on image for higher resolution image) Compare to the previous day's image
When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue (blue-green) is positive.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.
| Active region | Date numbered detected |
Spot count | Location at midnight | Area | Classification | SDO / HMI 4K continuum image with polarity overlay |
Comment | |||
|---|---|---|---|---|---|---|---|---|---|---|
| SWPC | STAR SDO | SWPC | STAR | Current | Previous | |||||
| 11225 | 2011.05.25 2011.05.27 |
1 | 4 | N16W48 | 0010 | AXX | AXX |
 |
 |
location: N16W46 |
| 11226 | 2011.05.27 | 19 | 28 | S21W25 | 0190 | DSI | DSI |
 |
 |
location: S23W25 |
| S1033 | 2011.05.28 | S18W56 | plage | |||||||
| 11228 | 2011.05.28 2011.05.29 |
7 | 7 | N17W08 | 0090 | DAO | CSO |
 |
 |
|
| 11227 | 2011.05.28 2011.05.29 |
7 | 11 | S19W14 | 0060 | CSO | CSO |
 |
 |
location: S23W08 |
| 11229 | 2011.05.29 2011.05.30 |
1 | 3 | N18W34 | 0000 | AXX | BXO |
 |
 |
location: N17W31 |
| 11230 | 2011.05.30 2011.05.31 |
1 | N20E06 | 0000 | AXX |
 |
plage |
|||
| 11232 | 2011.05.31 2011.06.01 |
1 | 5 | N10E33 | 0070 | HSX | CSO |
 |
 |
location: N08E34 |
| 11231 | 2011.06.01 2011.06.02 |
1 | N09E20 | 0000 | AXX |
 |
plage |
|||
| S1044 | 2011.06.01 | 5 | S19W16 | 0010 | BXO |
 |
 |
split off from 11227 on June 1 | ||
| S1045 | 2011.06.01 | S22W52 | plage | |||||||
| S1046 | 2011.06.03 | N15E22 |
 |
plage | ||||||
| S1047 | 2011.06.04 | 1 | S26E52 | 0000 | AXX |
 |
||||
| Total spot count: | 38 | 64 | ||||||||
| Sunspot number: | 118 | 144 | ||||||||
| Month | Average measured solar flux | International sunspot number (SIDC) | Smoothed sunspot number | Average ap (3) |
|---|---|---|---|---|
| 2008.07 | 65.7 (SF minimum) | 0.5 | 2.8 (-0.4) | |
| 2008.12 | 69.2 | 0.8 | 1.7 (-) sunspot minimum |
3.25 |
| 2010.02 | 84.7 | 18.8 | 10.6 (+1.3) | 4.15 / 4.61 |
| 2010.03 | 83.4 | 15.4 | 12.3 (+1.7) | 4.58 / 4.65 |
| 2010.04 | 75.9 | 8.0 | 14.0 (+1.7) | 10.22 / 10.24 |
| 2010.05 | 73.8 | 8.7 | 15.5 (+1.5) | 9.18 / 8.15 |
| 2010.06 | 72.5 | 13.6 | 16.4 (+0.9) | 8.17 / 6.85 |
| 2010.07 | 79.8 | 16.1 | 16.7 (+0.3) | 6.31 / 5.15 |
| 2010.08 | 79.2 | 19.6 | 17.4 (+0.7) | 8.49 / 7.77 |
| 2010.09 | 81.1 | 25.2 | 19.6 (+2.2) | 5.33 / 5.45 |
| 2010.10 | 81.6 | 23.5 | 23.2 (+3.6) | 6.07 / 6.27 |
| 2010.11 | 82.5 | 21.5 | 26.5 (+3.3) | 4.80 / 5.50 |
| 2010.12 | 84.2 | 14.4 | (29.4 predicted, +2.9) | 3.41 / 4.35 |
| 2011.01 | 83.6 | 19.1 | (32.6 predicted, +3.2) | 4.32 / 5.51 |
| 2011.02 | 94.6 | 29.4 | (35.2 predicted, +2.6) | 5.41 / 6.44 |
| 2011.03 | 115.0 | 56.2 | (37.5 predicted, +2.3) | 7.79 |
| 2011.04 | 112.6 | 54.4 | (40.4 predicted, +2.9) | 9.71 |
| 2011.05 | 95.8 | 41.6 | (43.7 predicted, +3.3) | 9.18 |
| 2011.06 | 108.8 (1) | 15.5 (2A) / 116.3 (2B) | (47.4 predicted, +3.7) | (9.84) |
1) Running average based on the daily 20:00 UTC observed solar flux value at
2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder
(NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The
official SIDC international sunspot number is typically 30-50% lower. 2B) Month
average to date.
3) Running average based on the preliminary daily SWPC ap indices.
Values in red are based on the official NGDC
ap indices.
This report has been prepared by Jan Alvestad. It is based on analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.
SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
