Recent activity

The geomagnetic field was quiet on June 27. Solar wind speed ranged between 360 and 465 km/s.

Solar flux measured at 20h UTC on 2.8 GHz was 89.2 (decreasing 22.8 over the last solar rotation). The planetary A index was 5 (STAR Ap - based on the mean of three hour interval ap indices: 5.0). Three hour interval K indices: 12111111 (planetary), 22212122 (Boulder).

The background x-ray flux is at the class B2 level.

At midnight UTC the visible solar disk had 6 spotted regions.

Region 11239 reemerged with a couple of spots. The region will rotate over the northwest limb today.
Region 11240 reemerged fairly quickly and could soon produce C flares.

Spotted regions not numbered by NOAA/SWPC:
[S1085] emerged in the northeast quadrant on June 26. Location at midnight: N16E07
[S1086] rotated into view at the northeast limb on June 27. Location at midnight: N17E80
[S1087] emerged in the northeast quadrant on June 27. Location at midnight: N17E43
[S1088] emerged in the southeast quadrant on June 27. Location at midnight: S25E32

Coronal mass ejections (CMEs)

June 25-27: No obviously earth directed CMEs were observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent coronal hole (CH460) in the northern hemisphere was in an Earth facing position on June 27. A small coronal hole (CH461) in the northern hemisphere will likely rotate into an Earth facing position on June 30-July 1. A small southern hemisphere coronal hole (CH462) could become Earth facing on July 2.

The above coronal hole map is based on a new method where coronal holes are detected automatically. The method may need some fine tuning, however, it has significant advantages over detecting coronal holes manually. The main improvement is the ability to detect coronal holes at and just beyond the solar limbs. Early results using this method for SDO images over a span of several weeks indicate a good match between coronal holes observed over the visible disk and their extent and position at the east and west limbs. Note that the polar coronal holes are easily detected using the new method, the extent and intensity of both holes are consistent with other data sources.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor.

Forecast

The geomagnetic field is expected to be quiet on June 28-29. Quiet to unsettled is likely on June 30-July 1 with a chance of active intervals due to effects from CH460.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)



1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions

(Click on image for higher resolution image) Compare to the previous day's image

When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue (blue-green) is positive.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered
detected
Spot count Location at midnight Area Classification SDO / HMI 4K continuum
image with polarity overlay
Comment
SWPC STAR SDO SWPC STAR Current Previous
11237 2011.06.16
2011.06.17
    S18W71           plage
11239 2011.06.17
2011.06.20
  2 N15W84 0010   BXO

location: N17W81

11240 2011.06.20 4 9 S18W53 0005 BXO CRO   area: 0030
S1076 2011.06.21     S09W42

plage

11241 2011.06.22
2011.06.24
6   N18W46 0010 BXO

plage

S1079 2011.06.23     N08W02           plage
S1083 2011.06.24     N25W13           plage
S1084 2011.06.25     N16W34           plage
S1085 2011.06.26   3 N16E07 0000   AXX
S1086 2011.06.27   2 N17E80 0030   CAO
S1087 2011.06.27   4 N17E43 0000   BXO
S1088 2011.06.27   1 S25E32 0000   AXX
Total spot count: 10 21
Sunspot number: 30 81

Monthly solar cycle data

Month Average measured solar flux International sunspot number (SIDC) Smoothed sunspot number Average ap
(3)
2008.07 65.7 (SF minimum) 0.5 2.8 (-0.4)
2008.12 69.2 0.8 1.7 (-)
sunspot minimum
3.25
2010.02 84.7 18.8 10.6 (+1.3) 4.15 / 4.61
2010.03 83.4 15.4 12.3 (+1.7) 4.58 / 4.65
2010.04 75.9 8.0 14.0 (+1.7) 10.22 / 10.24
2010.05 73.8 8.7 15.5 (+1.5) 9.18 / 8.15
2010.06 72.5 13.6 16.4 (+0.9) 8.17 / 6.85
2010.07 79.8 16.1 16.7 (+0.3) 6.31 / 5.15
2010.08 79.2 19.6 17.4 (+0.7) 8.49 / 7.77
2010.09 81.1 25.2 19.6 (+2.2) 5.33 / 5.45
2010.10 81.6 23.5 23.2 (+3.6) 6.07 / 6.27
2010.11 82.5 21.5 26.5 (+3.3) 4.80 / 5.50
2010.12 84.2 14.4 (29.4 predicted, +2.9) 3.41 / 4.35
2011.01 83.6 19.1 (32.6 predicted, +3.2) 4.32 / 5.51
2011.02 94.6 29.4 (35.2 predicted, +2.6) 5.41 / 6.44
2011.03 115.0 56.2 (37.5 predicted, +2.3) 7.79
2011.04 112.6 54.4 (40.4 predicted, +2.9) 9.71
2011.05 95.8 41.6 (43.7 predicted, +3.3) 9.18
2011.06 96.7 (1) 51.7 (2A) / 57.5 (2B) (47.4 predicted, +3.7) (9.52)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder (NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The official SIDC international sunspot number is typically 30-50% lower. 2B) Month average to date.
3) Running average based on the preliminary daily SWPC ap indices. Values in red are based on the official NGDC ap indices.

This report has been prepared by Jan Alvestad. It is based on analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.

SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
