The geomagnetic field was quiet to unsettled on January 13. Solar wind speed ranged between 361 and 412 km/sec.
Solar flux measured at 20h UTC on 2.8 GHz was 171.8. The planetary A
index was 8 (STAR Ap - based on the mean of three hour interval ap indices: 9.4).
Three hour interval K indices: 32123322 (planetary), 32112322 (Boulder).
The background x-ray flux is at the class B7 level.
At midnight there were 8 spotted regions on the visible disk, 2 of which have not yet been numbered. Solar flare activity was low. A total of 8 C class events were recorded during the day. Spotless region 10244 was the source of a C1.4 flare at 01:25, a C1.2 flare at 03:57 and a C4.2 flare at 16:15 UTC. A C2.4 event at 13:05 UTC appears to have been associated with an erupting prominence (image courtesy SOHO/EIT team) at the northeast limb.
Region 10242 rotated out of view at the southwest limb. Flares: C1.0 at 06:37, C3.1
at 14:11 and a C2.2 long duration event peaking at 22:40 UTC.
Region 10247 decayed slowly and quietly.
Region 10249 decayed further and will likely become spotless today.
Region 10250 was quiet and generally unchanged.
Region 10251 added some trailing spots and some small spots north of the large leading penumbra. An M class flare is
possible.
Region 10254 was mostly unchanged and quiet.
Region 10255 was split off from region 10251 on January 12 by SEC/NOAA. There are not yet any convincing arguments as to
why this split was necessary.
Region 10256 was split off from region 10254 on January 12 by SEC/NOAA.
Regions 10254 and 10256 make up one bipolar region with the negative polarity area in the west and the main positive
area to the east. It remains to be seen if SEC will merge the "two" regions again.
New region 10257 emerged quickly in the northeast quadrant.
Spotted regions not yet numbered by SEC/NOAA:
[S73] A new region emerged in the southwest quadrant before noon on January 13. The region is already decaying and could
become spotless early on January 14.
[S74] A new region rotated into view at the northeast limb before noon on January 13. Quite a bit of activity has been
observed at the northeast limb but I'm not yet sure if this activity has its origin in the trailing spots of this region or if
there is another region about to rotate into view. Flare: C1.5 at 04:36 UTC.
January 11-13: No obviously geoeffective CMEs observed.
Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28
days ago 27 days ago 26 days ago
No obvious coronal holes are currently approaching geoeffective positions.
Processed SOHO EIT 284 image at 19:06 UTC on January 13. Any black areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on January 14-18. Long distance medium wave (AM) band propagation along east-west paths over high and upper middle latitudes is fair.
| Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
 |
|
 |
1) Effects from a coronal hole could reach Earth within the
next 5 days.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48
hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Composite image based on a SOHO/MDI continuum image and overlaid by a coronal hole image. Region numbering has been included. Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by SEC/NOAA. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots.
| Solar region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
|---|---|---|---|---|---|---|---|
| 10242 | 2003.01.02 | 4 | S07W87 | 0120 | DAO | rotated out of view | |
| 10244 | 2003.01.03 | S22W84 | plage | ||||
| 10245 | 2003.01.03 | N12W59 | |||||
| 10246 | 2003.01.06 | N09W80 | plage | ||||
| 10247 | 2003.01.06 | 37 | 36 | S16W21 | 0150 | EAI | |
| 10249 | 2003.01.07 | 1 | 1 | S15W62 | 0020 | HRX | |
| 10250 | 2003.01.07 | 4 | 9 | S26E00 | 0130 | CAO | |
| 10251 | 2003.01.07 | 16 | 37 | S14E06 (SEC: S14E09) |
0080 | CAO |
beta-gamma classification was FKO at midnight, area 0280, region 10255 included |
| 10252 | 2003.01.09 | S03E05 | plage | ||||
| 10253 | 2003.01.10 | 5 | N11W77 (SEC: N09W73) |
0020 | CRO |
actually spotless location corrected, SEC spots are in region S72 |
|
| 10254 | 2003.01.10 | 2 | 4 | S15E37 (SEC: S14E29) |
0100 | HAX |
location corrected, classification was ESO at midnight, area 0170 STAR spot count includes region 10256 |
| 10255 | 2003.01.12 | 9 | S13E01 | 0200 | CKO |
split off from region 10251 |
|
| 10256 | 2003.01.12 | 1 | S17E41 | 0070 | HSX |
split off from region 10254. At midnight the area in question had only positive polarity spots. |
|
| 10257 | 2003.01.13 | 3 | 8 | N16E23 | 0010 | BXO |
classification was DAO at midnight, area 0040 |
| S72 | emerged on 2003.01.10 |
N07W72 | now spotless | ||||
| S73 | emerged on 2003.01.13 |
1 | S21W30 | 0000 | AXX | ||
| S74 | visible on 2003.01.13 |
6 | N06E70 | 0050 | CAO | ||
| Total spot count: | 82 | 102 | |||||
| SSN: | 182 | 182 | |||||
| Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
|---|---|---|---|
| 2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
| 2000.07 | 202.3 | 170.1 | 119.8 |
| 2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
| 2002.01 | 226.6 | 114.1 | 113.5 (-1.1) |
| 2002.02 | 205.0 | 107.4 | 114.6 (+1.2) |
| 2002.03 | 179.5 | 98.4 | 113.3 (-1.3) |
| 2002.04 | 189.8 | 120.7 | 110.5 (-2.9) |
| 2002.05 | 178.4 | 120.8 | 108.8 (-1.7) |
| 2002.06 | 148.7 | 88.3 | 106.2 (-2.6) |
| 2002.07 | 173.5 | 99.6 | (102.1 predicted, -4.1) |
| 2002.08 | 183.6 | 116.4 | (98.5 predicted, -3.6) |
| 2002.09 | 175.8 | 109.6 | (95.5 predicted, -3.0) |
| 2002.10 | 167.0 | 97.5 | (92.0 predicted, -3.5) |
| 2002.11 | 168.7 | 95.0 | (86.7 predicted, -5.3) |
| 2002.12 | 157.2 | 81.6 | (82.4 predicted, -4.3) |
| 2003.01 | 158.7 (1) | 66.7 (2) | (79.4 predicted, -3.0) |
1) Running average based on the daily 20:00 UT observed solar flux value at 2800
MHz.
2) Unofficial, accumulated value based on the Boulder (SEC/NOAA) sunspot number. The official
international sunspot number is typically 25-45% less.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and interpretations, and partly on data from sources noted in solar links. All time references are to the UTC day. Comments and suggestions are always welcome.
