Recent activity

The geomagnetic field was quiet to minor storm on August 7. Solar wind speed ranged between 323 and 510 km/sec under the influence of a low to medium high speed stream from coronal hole CH107.

Solar flux measured at 20h UTC on 2.8 GHz was 94.6. The planetary A index was 20 (STAR Ap - based on the mean of three hour interval ap indices: 21.1).
Three hour interval K indices: 33544323 (planetary), 33544222 (Boulder).

The background x-ray flux is at the class B1 level.

At midnight there were 4 spotted regions on the visible disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10655 decayed further with no trailing spots having penumbra, quite a few small spots disappeared.
Region 10656 developed slowly adding penumbra to a few trailing spots.
Region 10657 was quiet and stable.
New region 10658 emerged early in the day to the northwest of region 10656. Penumbra was visible on a single spot, then the region decayed and only a single tiny spot was visible at the end of the day.

Coronal mass ejections (CMEs)

August 5-7: No obviously Earth directed CMEs were detected in LASCO images.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

The northernmost extension of a coronal hole (CH108) in the southern hemisphere may have been in a geoeffective position on August 7. The southernmost extensions of a poorly defined coronal hole (CH109) in the northern hemisphere will be in geoeffective positions on August 8-9.

Processed SOHO/EIT 284 image at 01:06 UTC on August 8. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on August 8-9 with conditions becoming quiet to active on August 10-12 due to effects from coronal holes CH108 and CH109.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation along long distance north-south paths is poor to fair. Trans Atlantic propagation conditions are monitored every night on 1470 kHz. Dominant stations tonight: Radio Vibración (Venezuela) and Radio Cristal del Uruguay. Some stations from Brazil were noted before local sunrise with the most interesting signal from Floresta AM on 1590 kHz. Only a few stations from North America could be heard, WWZN Boston on 1510 kHz had a fair and stable signal for a long time.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10655 2004.07.30 22 15 S10W38 0230 FSI classification was CAI,
area 0140 at midnight
10656 2004.08.06 7 10 S13E58 0250 DKO classification was DAO,
area 0150 at midnight
10657 2004.08.06 1 1 N11E65 0060 HAX area was 0040
at midnight
10658 2004.08.07 1 1 S06E50 0020 HSX classification was AXX,
area 0000 at midnight
S441 emerged on
2004.08.03
    N16W39     plage
Total spot count: 31 27
SSN: 71 67

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.06 129.3 77.4 65.0 (-2.6)
2003.07 127.7 83.3 61.8 (-3.2)
2003.08 122.1 72.7 60.1 (-1.7)
2003.09 112.2 48.7 59.6 (-0.5)
2003.10 151.7 65.5 58.2 (-1.4)
2003.11 140.8 67.3 56.8 (-1.4)
2003.12 114.9 46.5 54.8 (-2.0)
2004.01 114.1 37.7 52.0 (-2.8)
2004.02 107.0 45.8 (49.1 predicted, -2.9)
2004.03 112.0 49.1 (46.5 predicted, -2.6)
2004.04 101.2 39.3 (44.3 predicted, -2.2)
2004.05 99.8 41.5 (41.0 predicted, -3.3)
2004.06 97.4 43.2 (38.2 predicted, -2.8)
2004.07 119.1 51.0 (36.3 predicted, -1.9)
2004.08 87.8 (1) 11.4 (2) (34.9 predicted, -1.4)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
