Recent activity

The geomagnetic field was quiet to unsettled on August 14. Solar wind speed ranged between 384 and 446 km/sec.

Solar flux measured at 20h UTC on 2.8 GHz was 149.2. The planetary A index was 9 (STAR Ap - based on the mean of three hour interval ap indices: 10.3).
Three hour interval K indices: 31233322 (planetary), 21222322 (Boulder).

The background x-ray flux is at the class C1 level.

At midnight there were 4 spotted regions on the visible disk. The solar flare activity level was high. A total of 7 C and 8 M class events was recorded during the day.

Region 10656 continued to change appearance with some decay observed in and near the central penumbra. Further development was observed in the trailing spots section where negative polarity emerged in several places. Further major flares are possible. Flares: M2.4 at 04:14, M7.4/2N, M2.3/1F at 07:56, C8.0 at 09:29, M3.2/1F at 10:07, C7.4 at 12:11, M5.6/2N at 13:43, C5.9 at 15:25, C5.2 at 16:47, C4.1 at 17:45, M1.3 at 18:18, M1.3 at 20:16, M1.2 at 20:47 (not mentioned by SEC, the event movie clearly displays the origin of this event as being different from the earlier M1.3 flare), C2.1 at 22:16 and C2.8 at 23:27 UTC.
Region 10657 decayed slowly and quietly.
Region 10660 decayed slowly and quietly.
Region 10661 added a few small trailing spots, no significant changes were noted in the two penumbrae.

Coronal mass ejections (CMEs)

August 12: No obviously Earth directed CMEs were detected in LASCO images.
August 13-14: Several small CMEs were observed over the south pole and the southwest limb after flare activity in region 10656. While none of these CMEs had any obvious Earth directed components, there is a chance that some of the ejected material could reach Earth.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently approaching geoeffective positions.

Processed SOHO/EIT 284 image at 01:06 UTC on August 15. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on August 15-17.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are monitored every night on 1470 kHz. Dominant stations tonight: Radio Cristal del Uruguay and Radio Rafaela on the inverted L, Radio Vibración on the EWE. Propagation favored the northeastern part of North America. The New York stations on 1130, 1540 and 1560 all had good signals as did WWZN 1510 and Radio Disney on 1650 kHz. At local sunrise quite a few stations from Venezuela were noted above 1350 kHz.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10656 2004.08.06 66 91 S13W35 1300 FKC beta-gamma-delta
10657 2004.08.06 2 2 N10W28 0020 HSX
10658 2004.08.07     S05W40     plage
10659 2004.08.10     N18E07     plage
10660 2004.08.11 1 1 S07E17 0030 HSX
10661 2004.08.12 2 8 N07E60 0340 DAO classification was CKO
at midnight
S444 emerged on
2004.08.09
    S10W06     plage
Total spot count: 71 102
SSN: 111 142

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.06 129.3 77.4 65.0 (-2.6)
2003.07 127.7 83.3 61.8 (-3.2)
2003.08 122.1 72.7 60.1 (-1.7)
2003.09 112.2 48.7 59.6 (-0.5)
2003.10 151.7 65.5 58.2 (-1.4)
2003.11 140.8 67.3 56.8 (-1.4)
2003.12 114.9 46.5 54.8 (-2.0)
2004.01 114.1 37.7 52.0 (-2.8)
2004.02 107.0 45.8 (49.1 predicted, -2.9)
2004.03 112.0 49.1 (46.5 predicted, -2.6)
2004.04 101.2 39.3 (44.3 predicted, -2.2)
2004.05 99.8 41.5 (41.0 predicted, -3.3)
2004.06 97.4 43.2 (38.2 predicted, -2.8)
2004.07 119.1 51.0 (36.3 predicted, -1.9)
2004.08 109.3 (1) 37.1 (2) (34.9 predicted, -1.4)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
