Recent activity

The geomagnetic field was quiet on August 24. Solar wind speed ranged between 300 and 462 km/sec.

Solar flux measured at 20h UTC on 2.8 GHz was 104.9. The planetary A index was 5 (STAR Ap - based on the mean of three hour interval ap indices: 6.1).
Three hour interval K indices: 21112222 (planetary), 20223321 (Boulder).

The background x-ray flux is at the class B1-B2 level.

At midnight there were 3 spotted regions on the visible disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10661 decayed slowly and quietly.
Region 10663 decayed further but still has several tiny trailing spots.
Region 10664 decayed slowly and quietly.

Coronal mass ejections (CMEs)

August 22-24: No obviously Earth directed CMEs were observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

The northernmost extension of a coronal hole (CH110) in the southern hemisphere was likely in a geoeffective position on August 21.

Processed SOHO/EIT 284 image at 01:06 UTC on August 25. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on August 25-28. There is still a chance of a weak coronal hole flow arriving on August 25.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are monitored every night on 1470 kHz. Dominant stations tonight: Radio Vibración (Venezuela). Propagation in general was best towards Venezuela and Puerto Rico (1430, 1480, 1600 and 1660 kHz). A number of stations from North America were observed throughout the MW band, most with weak signals and from the northeastern part of the US and the Canadian Atlantic.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10661 2004.08.12 3 4 N06W73 0320 DHO classification was CAO
at midnight
10662 2004.08.18     N14W54     plage
10663 2004.08.19 5 8 N10E12 0100 CSO
10664 2004.08.20 17 15 S11W16 0140 ESO classification was EAO
at midnight
10665 2004.08.22     N05W41     plage
S448 emerged on
2004.08.22
    N09W45     plage
Total spot count: 25 27
SSN: 55 57

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.06 129.3 77.4 65.0 (-2.6)
2003.07 127.7 83.3 61.8 (-3.2)
2003.08 122.1 72.7 60.1 (-1.7)
2003.09 112.2 48.7 59.6 (-0.5)
2003.10 151.7 65.5 58.2 (-1.4)
2003.11 140.8 67.3 56.8 (-1.4)
2003.12 114.9 46.5 54.8 (-2.0)
2004.01 114.1 37.7 52.0 (-2.8)
2004.02 107.0 45.8 (49.1 predicted, -2.9)
2004.03 112.0 49.1 (46.5 predicted, -2.6)
2004.04 101.2 39.3 (44.3 predicted, -2.2)
2004.05 99.8 41.5 (41.0 predicted, -3.3)
2004.06 97.4 43.2 (38.2 predicted, -2.8)
2004.07 119.1 51.0 (36.3 predicted, -1.9)
2004.08 114.9 (1) 61.7 (2) (34.9 predicted, -1.4)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
