The geomagnetic field was quiet to unsettled on June 10. Solar wind speed ranged between 392 and 528 km/sec.
Solar flux measured at 20h UTC on 2.8 GHz was 82.5. The planetary A
index was 11 (STAR Ap - based on the mean of three hour interval ap indices: 12.0).
Three hour interval K indices: 33223333 (planetary), 33212123 (Boulder).
The background x-ray flux is at the class A4 level.
At midnight there were 3 spotted regions on the visible disk. The solar flare activity level was very low. No C class events were recorded during the day.
Region 10622 was mostly unchanged and quiet.
Region 10631 developed slowly and quietly.
New region 10632 rotated into view on June 9 and was numbered the next day by SEC.
June 8-10: No fully or partly Earth directed CMEs observed.
Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
A recurrent coronal hole (CH101) in the southern hemisphere will likely rotate into a geoeffective position on June 12-13.
Processed SOHO/EIT 284 image at 19:05 UTC on June 10. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on June 11-14 and quiet to active on June 15-16 due to a high speed stream from coronal hole CH101.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation along long distance north-south paths is fair. Trans Atlantic propagation conditions are monitored every night on 1470 kHz. Dominant stations tonight: Radio Cristal del Uruguay and Radio Vibración (Venezuela). Propagation was best after local sunrise and then favoring signals from Uruguay, Argentina and Venezuela. The best stations were noted on 930, 950, 970, 1010, 1470 and 1590 kHz.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
classification was BXO
at midnight, area 0010
area was 0030
formerly region S415
area was 0070
|Total spot count:||10||9|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2003.12||114.9||46.5||(54.4 predicted, -2.3)|
|2004.01||114.1||37.2||(50.5 predicted, -3.9)|
|2004.02||107.0||46.0||(46.2 predicted, -4.3)|
|2004.03||112.0||48.9||(43.5 predicted, -2.7)|
|2004.04||101.2||39.3||(41.4 predicted, -2.1)|
|2004.05||99.8||41.5||(38.2 predicted, -3.2)|
|2004.06||87.5 (1)||22.2 (2)||(35.3 predicted, -2.9)|
1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
