Solar Terrestrial Activity Report

Last major update issued on February 13, 2005 at 04:25 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update January 2, 2005)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update January 2, 2005)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update January 2, 2005)]
[Historical solar and geomagnetic data charts 1954-2004 (last update February 1, 2005)]
[Archived reports (last update February 1, 2005)]

Recent activity

The geomagnetic field was quiet on February 12. Solar wind speed ranged between 452 and 576 km/sec, generally decreasing all day.

Solar flux measured at 20h UTC on 2.8 GHz was 116.4. The planetary A index was 5 (STAR Ap - based on the mean of three hour interval ap indices: 4.8).
Three hour interval K indices: 22111120 (planetary), 22122220 (Boulder).

The background x-ray flux is at the class B2 level.

At midnight there were 5 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10730 decayed slowly and quietly.
Region 10732 changed appearance with most of the small spots disappearing. Instead several new spots emerged inside a smaller area.
Region 10733 was quiet and stable.
Region 10734 was quiet and stable.
Region 10735 became less complex as the positive polarity spot in the southeast separated from the main penumbra.

Coronal mass ejections (CMEs)

February 10-11: No obvious fully or partly Earth directed CMEs were observed. Data for February 12 is currently unavailable.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent coronal hole (CH145) in the northern hemisphere will likely rotate to a geoeffective position on February 13-15. A small coronal hole (CH146) in the southern hemisphere was in a potentially geoeffective position on February 11.

Processed SOHO/EIT 284 image at 01:06 UTC on February 13. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on February 13-15 with a chance of a few active intervals on February 14 due to a low speed stream from CH146. A high speed stream from CH145 could arrive on February 16 and cause unsettled to minor storm conditions until February 18.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: WLAM Lewiston ME and WWNN Boca Raton FL. Most other stations heard on other frequencies were from the US and Canada with the strongest signals from 1500 WTOP, 1510 WWZN, 1570 CFAV and 1600 WUNR.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10730 2005.02.04 4 3 S20W32 0010 AXX classification was HAX at midnight, area 0030
10731 2005.02.06     S02W51     plage
10732 2005.02.06 14 12 N11W17 0090 ESO classification was
DAO at midnight, area 0050
10733 2005.02.07 2 5 S08E14 0250 HAX classification was
CAO at midnight
10734 2005.02.09 1 1 S05E31 0060 HSX
10735 2005.02.10 1 5 S08E47 0380 HHX classification was DHO at midnight
S509 emerged on
2005.02.09
    S07W31     plage
S511 emerged on
2005.02.11
    S06E20     plage
Total spot count: 22 26
SSN: 72 76

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.12 114.9 46.5 54.8 (-1.9)
2004.01 114.1 37.3 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 47.1 (-2.2)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.9 (-1.6)
2004.06 97.4 43.2 41.7 (-2.2)
2004.07 119.1 51.0 40.3 (-1.4)
2004.08 109.6 40.9 (38.9 predicted, -1.4)
2004.09 103.1 27.7 (36.6 predicted, -2.3)
2004.10 105.9 48.4 (34.4 predicted, -2.2)
2004.11 113.2 43.7 (32.5 predicted, -1.9)
2004.12 94.5 17.9 (30.2 predicted, -2.3)
2005.01 102.2 31.3 (27.6 predicted, -2.6)
2005.02 98.9 (1) 21.5 (2) (25.2 predicted, -2.4)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
