The geomagnetic field was quiet to unsettled on July 7. Solar wind speed ranged between 324 and 358 (all day average 346) km/sec.
Solar flux measured at 20h UTC on 2.8 GHz was 124.9. The planetary
A
index was 8 (STAR Ap - based on the mean of three hour interval ap
indices: 7.9).
Three hour interval K indices: 21212223 (planetary), 11223313 (Boulder).
The background x-ray flux is at the class B3 level.
At midnight there were 4 spotted regions on the visible solar disk. The solar flare activity level was moderate. A total of 5 C and 1 M class events was recorded during the day.
Region 10783 decayed in the trailing spot section while slow growth was observed in the intermediate spot section. A minor
M class flare is possible.
Region 10786 decayed slightly after the M flare. Another M class flare is possible as there is still at least one
magnetic delta structure. Flares: C1.6 at 08:01, C3.8 at 13:29 and M4.9 at 16:29 UTC. A strong
type IV radio sweep accompanied the M flare
Region 10788 added a few small spots ahead of the single penumbra.
Region 10789 decayed slightly as the separation between the positive and negative polarity areas increased. Flares:
C1.2 at 08:39, C2.6 at 12:29 and C2.7 at 15:19 UTC.
July 7: A filament eruption which started at approximately 11h UTC just south of region 10786 was the likely source of a
full halo CME observed in LASCO C3 images beginning at 14:42 UTC. Another full halo CME was observed in LASCO C3 images beginning
at 18:18 UTC. Its source was likely the M4.9 flare in region 10786. The CME was not very impressive.
July 6: No obvious fully or partly Earth directed CMEs were observed in available LASCO images.
July 5: A faint full halo CME was observed beginning at 16:18 UTC in LASCO C3 images when material was first
observed over the southeast limb.
Coronal hole
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28
days ago 27 days ago 26
days ago
An extension of a coronal hole (CH174) in the southern hemisphere may have been in an Earth facing position on July 5-6.
Processed SOHO/EIT 284 image at 01:06 UTC on July 8. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to active on July 8 due to a weak stream from CH174 and possibly effects from a CME observed on July 5. Two CMEs could arrive late on July 9 and cause unsettled to minor storm conditions.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next
48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation along long distance north-south paths is fair. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: Radio Cristal del Uruguay and Radio Vibración (Venezuela). Propagation towards Argentina and Uruguay was poor before 02:30 UTC and improved remarkably 10 minutes after local sunrise. Fair signals were noted on both 1480 and 1500 kHz. From North America the Newfoundland stations on 590, 750 and 930 and WWZN on 1510 kHz had poor to fair signals.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
Active region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
10781 | 2005.06.27 | 3 | N14W51 | 0010 | BXO | spotless for the second consecutive day | |
10783 | 2005.06.29 | 30 | 34 | S03W49 | 0430 | EAI | |
10784 | 2005.06.29 | 4 | N16W38 | 0010 | BXO | spotless | |
10785 | 2005.06.30 | S19W72 | plage | ||||
10786 | 2005.07.01 | 40 | 42 | N12W04 | 0420 | DHI |
beta-gamma-delta classification was DKC at midnight, area 0630 |
10788 | 2005.07.02 | 2 | 3 | S06E03 | 0080 | HSX | classification was CSO at midnight |
10789 | 2005.07.03 | 10 | 12 | N17E40 | 0200 | DSO | beta-gamma |
S563 | 2005.06.27 | N10W82 | plage | ||||
S567 | 2005.07.03 | S07E11 | plage | ||||
Total spot count: | 89 | 91 | |||||
SSN: | 149 | 131 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2004.05 | 99.8 | 41.5 | 43.8 (-1.7) |
2004.06 | 97.4 | 43.2 | 41.6 (-2.2) |
2004.07 | 119.1 | 51.1 | 40.2 (-1.4) |
2004.08 | 109.6 | 40.9 | 39.2 (-1.0) |
2004.09 | 103.1 | 27.7 | 37.5 (-1.7) |
2004.10 | 105.9 | 48.0 | 35.9 (-1.6) |
2004.11 | 113.2 | 43.5 | 35.3 (-0.6) |
2004.12 | 94.5 | 17.9 | 35.2 (-0.1) |
2005.01 | 102.2 | 31.3 | (34.6 predicted, -0.6) |
2005.02 | 97.2 | 29.1 | (33.3 predicted, -1.3) |
2005.03 | 89.9 | 24.8 | (31.6 predicted, -1.7) |
2005.04 | 86.0 | 24.4 | (29.7 predicted, -1.9) |
2005.05 | 99.3 | 42.6 | (27.2 predicted, -2.5) |
2005.06 | 93.7 | 39.3 | (25.7 predicted, -1.5) |
2005.07 | 123.7 (1) | 36.6 (2) | (24.7 predicted, -1.0) |
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC)
sunspot number. The official international sunspot number is typically
30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
