Solar Terrestrial Activity Report

Last major update issued on June 22, 2005 at 04:40 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update June 4, 2005)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update June 4, 2005)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update June 4, 2005)]
[Historical solar and geomagnetic data charts 1954-2004 (last update February 1, 2005)]
[Archived reports (last update June 21, 2005)]

Recent activity

The geomagnetic field was inactive to quiet on June 21. Solar wind speed ranged between 339 and 349 km/sec.

Solar flux measured at 20h UTC on 2.8 GHz was 83. The planetary A index was 4 (STAR Ap - based on the mean of three hour interval ap indices: 3.8).
Three hour interval K indices: 10001121 (planetary), 10000011 (Boulder).

The background x-ray flux is at the class A7 level.

At midnight there were 2 spotted regions on the visible solar disk. The solar flare activity level was low. A single C class event was recorded during the day.

Region 10779 decayed further and was quiet. The region will rotate over the southwest limb today.
Region 10780 developed early in the day, then began to decay. Flare: C2.1 at 18:04 UTC.

Coronal mass ejections (CMEs)

June 19-21: No obvious fully or partly Earth directed CMEs were observed in available LASCO images.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent coronal hole (CH171) in the northern hemisphere will be in an Earth facing position on June 21-23.

Processed SOHO/EIT 284 image at 01:06 UTC on June 6. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be mostly quiet on June 22-23 becoming unsettled to active on June 24-25 due to a high speed stream from CH171.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation along long distance north-south paths is fair. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Cristal del Uruguay. On other frequencies quite a few stations from Brazil were noted, particularly stations from Ceará (760, 930 kHz and other frequencies) had fair to good signals.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10777 2005.06.10     N05W89     plage
10779 2005.06.15 13 11 S16W71 0250 EAI classification was EAO at midnight
10780 2005.06.17 20 20 S07E12 0090 DAI
S560 2005.06.16     N08W28     plage
Total spot count: 33 31
SSN: 53 51

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.8 (-1.7)
2004.06 97.4 43.2 41.6 (-2.2)
2004.07 119.1 51.1 40.2 (-1.4)
2004.08 109.6 40.9 39.2 (-1.0)
2004.09 103.1 27.7 37.5 (-1.7)
2004.10 105.9 48.0 35.9 (-1.6)
2004.11 113.2 43.5 35.3 (-0.6)
2004.12 94.5 17.9 (34.8 predicted, -0.5)
2005.01 102.2 31.3 (32.8 predicted, -2.0)
2005.02 97.2 29.1 (30.4 predicted, -2.4)
2005.03 89.9 24.8 (28.8 predicted, -1.6)
2005.04 86.0 24.4 (26.9 predicted, -1.9)
2005.05 99.3 42.6 (24.3 predicted, -2.6)
2005.06 98.8 (1) 50.8 (2) (22.8 predicted, -1.5)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
