The geomagnetic field was quiet to active on September 5. Solar wind speed ranged between 442 and 663 (all day average 524) km/sec, slowly decreasing all day.
Solar flux measured at 20h UTC on 2.8 GHz was 75.0. The planetary
A
index was 14 (STAR Ap - based on the mean of three hour interval ap
indices: 14.3).
Three hour interval K indices: 42342332 (planetary), 42342332 (Boulder).
The background x-ray flux is at the class B1 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was low. A single C class event was recorded during the day, a very long duration C2.7 event peaking at 10:41 UTC from a source a couple of days behind the southeast limb.
Region 10805 decayed slowly and quietly.
September 2-4: At 03:42 UTC on September 3 another large, full halo CME was observed in LASCO images. The source was about 3-4 days behind the southeast limb. This backsided region has produced several large CMEs over the last week. A CME was observed over the west limbs following a long duration C2 event in region 10803 during the afternoon on September 4. A backsided, large full halo CME was observed after the LDE in old region 10798 behind the southeast limb near noon on September 5.
Coronal hole
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28
days ago 27 days ago 26
days ago
A poorly defined recurrent coronal hole (CH186) in the northern hemisphere will likely be in an Earth facing position on September 4-5. A recurrent trans equatorial coronal hole (CH187) will rotate to an Earth facing position on September 8-10.
Processed SOHO/EIT 284 image at 13:06 UTC on September 2. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to active on September 5 and quiet to unsettled on September 6. Effects from CH186 are possible on September 7-8 with some unsettled to active intervals likely.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next
48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Cristal del Uruguay. The only station from North America was VOWR on 800 kHz. Some stations from Argentina, Brazil and Uruguay were heard throughout the band with mostly poor signals.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
Active region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
10803 | 2005.08.24 | N11W78 | plage | ||||
10805 | 2005.08.27 | 2 | 2 | S11W44 | 0040 | HAX | |
10806 | 2005.08.29 | S16W45 | plage | ||||
S588 | 2005.08.31 | N12W36 | plage | ||||
Total spot count: | 2 | 2 | |||||
SSN: | 12 | 12 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2004.07 | 119.1 | 51.1 | 40.2 (-1.4) |
2004.08 | 109.6 | 40.9 | 39.2 (-1.0) |
2004.09 | 103.1 | 27.7 | 37.5 (-1.7) |
2004.10 | 105.9 | 48.0 | 35.9 (-1.6) |
2004.11 | 113.2 | 43.5 | 35.3 (-0.6) |
2004.12 | 94.5 | 17.9 | 35.2 (-0.1) |
2005.01 | 102.2 | 31.3 | 34.6 (-0.6) |
2005.02 | 97.2 | 29.2 | 33.9 (-0.7) |
2005.03 | 89.9 | 24.5 | (33.5 predicted, -0.4) |
2005.04 | 86.0 | 24.4 | (32.2 predicted, -1.3) |
2005.05 | 99.3 | 42.6 | (29.9 predicted, -2.3) |
2005.06 | 93.7 | 39.6 | (28.7 predicted, -1.2) |
2005.07 | 96.4 | 39.9 | (27.7 predicted, -1.0) |
2005.08 | 90.5 | 36.4 | (25.8 predicted, -1.9) |
2005.09 | 76.0 (1) | 3.0 (2) | (24.2 predicted, -1.6) |
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC)
sunspot number. The official international sunspot number is typically
30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
