The geomagnetic field was quiet to unsettled on September 22. Solar wind speed ranged between 309 and 355 (all day average 340) km/sec.
Solar flux measured at 20h UTC on 2.8 GHz was 83.7. The planetary
index was 8 (STAR Ap - based on the mean of three hour interval ap
Three hour interval K indices: 22212321 (planetary), 13233211 (Boulder).
The background x-ray flux is at the class A4 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.
Region 10810 was quiet. Some new small spots emerged, mainly in the leading positive polarity area.
September 20-22: No obvious fully or partly Earth directed CMEs were observed.
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
A recurrent, poorly defined trans equatorial coronal hole (CH188) was in an Earth facing position on September 22-23.
Processed TRACE mosaic image on September 22, 2005. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on September 23-25 with a possibility of active intervals on September 25 if a high speed stream from CH188 arrives.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor to fair. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Vibración (Venezuela). Propagation was mixed with the most usual stations from Venezuela, Colombia and the easternmost parts of North America all noted between 02 and 03:30 UTC.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
|10810||2005.09.17||18||15||N09E07||0230||DKI||classification was CKI at midnight, area 0280|
|Total spot count:||18||15|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2005.03||89.9||24.5||(33.5 predicted, -0.4)|
|2005.04||86.0||24.4||(32.2 predicted, -1.3)|
|2005.05||99.3||42.6||(29.9 predicted, -2.3)|
|2005.06||93.7||39.6||(28.7 predicted, -1.2)|
|2005.07||96.4||39.9||(27.7 predicted, -1.0)|
|2005.08||90.5||36.4||(25.8 predicted, -1.9)|
|2005.09||95.9 (1)||32.0 (2)||(24.2 predicted, -1.6)|
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
