The geomagnetic field was quiet to active on August 29. Solar wind speed ranged between 514 and 559 km/s (all day average 541 km/s - decreasing 48 km/s from the previous day).
Solar flux measured at 20h UTC on 2.8 GHz was 73.0. The planetary A index was 9 (STAR Ap - based on the mean of three hour interval ap indices: 9.1). Three hour interval K indices: 22341222 (planetary), 22341101 (Boulder).
The background x-ray flux is at the class A3 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was low. A total of 2 C class events was recorded during the day.
Region 10905 decayed further and lost the trailing spots. Flares: C1.4 at 14:45 and C2.1 at 15:29 UTC.
August 27-20: No partly or fully Earth directed CMEs were detected in incomplete LASCO imagery.
Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
A recurrent trans equatorial coronal hole (CH238) will rotate into an Earth facing position on August 29-31.
Processed SOHO/EIT 284 image at 19:08 UTC on August 18. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on August 31. A high speed stream from CH238 can cause unsettled to major storm conditions on September 1-3.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Some of the Newfoundland stations were heard with fair signals. 1660 WCNZ was there as well while stations from the northeastern US states had only very weak signals. The best signals were noted from stations from Venezuela and the Caribbean. Propagation on long distance northeast-southwest paths is fair with several stations from Uruguay and Argentina reaching fair and occasionally good signal levels.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
|Total spot count:||20||14|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2006.02||76.5||4.7||(18.4 predicted, -2.4)|
|2006.03||75.4||10.8||(16.6 predicted, -1.8)|
|2006.04||89.0||30.2||(15.9 predicted, -0.7)|
|2006.05||80.9||22.2||(15.1 predicted, -0.8)|
|2006.06||76.5||13.9||(12.9 predicted, -2.2)|
|2006.07||75.7||12.2||(11.4 predicted, -1.5)|
|2006.08||79.2 (1)||20.9 (2)||(11.4 predicted, -0.0)|
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
