Solar Terrestrial Activity Report

Last major update issued on July 17, 2006 at 02:30 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update June 7, 2006)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update June 7, 2006)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update June 7, 2006)]
[Historical solar and geomagnetic data charts 1954-2005 (last update March 3, 2006)]
[Archived reports (last update July 9, 2006)]

Recent activity

The geomagnetic field was quiet on July 16. Solar wind speed ranged between 347 and 408 km/s (all day average 360 km/s - decreasing 77 km/s from the previous day).

Solar flux measured at 20h UTC on 2.8 GHz was 70.8. The planetary A index was 4 (STAR Ap - based on the mean of three hour interval ap indices: 3.6).
Three hour interval K indices: 12101101 (planetary), 03200011 (Boulder).

The background x-ray flux is below the class A1 level.

At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10900 developed with several new spots emerging and penumbra forming on both polarities.

Coronal mass ejections (CMEs)

July 14-16: No partly or fully Earth directed CMEs were detected in LASCO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently in or approaching Earth facing locations.

Processed SOHO/EIT 284 image at 19:06 UTC on July 16. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet on July 17-20.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Both Radio Vibración (Venezuela) and Radio Cristal del Uruguay were noted at times tonight with weak signals. After 02h UTC some stations from Argentina became audible. After 01h UTC several stations from North America became audible with the best signal from 1130 WBBR. Strong carriers were observed on many NA frequencies.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10899 2006.07.05     S05W79     plage
10900 2006.07.14 10 10 S06E16 0040 BXO classification was DAI at midnight, area 0060
S668 2006.07.15     S04E23     plage
Total spot count: 10 10
SSN: 20 20

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2005.05 99.3 42.7 28.9 (-2.7)
2005.06 93.7 39.3 28.8 (-0.1)
2005.07 96.4 40.1 29.1 (+0.3)
2005.08 90.5 36.4 27.4 (-1.7)
2005.09 91.1 21.9 25.8 (-1.6)
2005.10 77.0 8.5 25.5 (-0.3)
2005.11 86.3 18.0 24.9 (-0.6)
2005.12 90.7 41.2 23.0 (-1.9)
2006.01 83.4 15.4 (20.7 predicted, -2.3)
2006.02 76.5 4.7 (18.2 predicted, -2.5)
2006.03 75.4 10.8 (16.4 predicted, -1.8)
2006.04 89.0 30.2 (15.7 predicted, -0.7)
2006.05 80.9 22.2 (14.9 predicted, -0.8)
2006.06 76.5 13.9 (12.7 predicted, -2.2)
2006.07 77.8 (1) 13.5 (2) (11.3 predicted, -1.4)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
