The geomagnetic field was quiet to unsettled on June 19. Solar wind speed ranged between 405 and 534 km/s (all day average 463 km/s - decreasing 90 km/s from the previous day).
Solar flux measured at 20h UTC on 2.8 GHz was 73.3. The planetary A index
was 5 (STAR Ap - based on the mean of three hour interval ap
Three hour interval K indices: 31000112 (planetary), 31110100 (Boulder).
The background x-ray flux is below the class A1 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.
Region 10896 decayed slowly and was mostly quiet.
June 17-19: No partly or fully Earth directed CMEs were observed in LASCO imagery.
Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
No obvious coronal holes are currently in or near Earth facing positions.
Processed SOHO/EIT 284 image at 19:06 UTC on June 19. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet on June 20-23.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is fair to good. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Radio Cristal del Uruguay was the best signal. Propagation on other frequencies was best to Brazil with several stations noted on 1390, 1400 and 1540 kHz. Rádio Boas Novas on 580 kHz was heard well at 03h UTC, 30 minutes after LSR. From Argentina 1190 Radio América had an impressive signal while the Paraguay station with the same name was easily audible on 1480 kHz.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
|10896||2006.06.17||11||8||S11E03||0040||DRO||classification was DSO at midnight|
|Total spot count:||11||8|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2005.12||90.7||41.2||(22.8 predicted, -2.1)|
|2006.01||83.4||15.4||(20.1 predicted, -2.7)|
|2006.02||76.5||4.7||(17.1 predicted, -3.0)|
|2006.03||75.4||10.8||(15.1 predicted, -2.0)|
|2006.04||89.0||30.2||(14.4 predicted, -0.7)|
|2006.05||80.9||22.2||(13.5 predicted, -0.9)|
|2006.06||76.3 (1)||17.4 (2)||(11.4 predicted, -2.1)|
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
