The geomagnetic field was inactive to quiet on June 21. Solar wind speed ranged between 274 and 363 km/s (all day average 333 km/s - decreasing 39 km/s from the previous day).
Solar flux measured at 20h UTC on 2.8 GHz was 72.7. The planetary A index
was 4 (STAR Ap - based on the mean of three hour interval ap
Three hour interval K indices: 10001212 (planetary), 10111012 (Boulder).
The background x-ray flux is below the class A1 level.
At midnight the visible solar disk was spotless. The solar flare activity level was very low. No C class events were recorded during the day.
June 19-21: No partly or fully Earth directed CMEs were detected in LASCO imagery.
Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
A recurrent trans equatorial coronal hole (CH229) will likely be in an Earth facing position on June 25-26.
Processed SOHO/EIT 284 image at 19:06 UTC on June 21. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be mostly quiet on June 22-25.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is good to very good. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Radio Cristal del Uruguay had a strong signal at times. On other frequencies propagation was unusually good for stations near Buenos Aires and Montevideo. Normally hard to hear Radio América (Uruguay) on 1450 kHz had a clear and strong signal despite strong European stations on 1449 kHz, and actually had competition at times from an unidentified station from Argentina. On 1540 kHz Radio Mon (Pergamino, Argentina) had the best signal I've ever heard them with. 1510 kHz was a mess with several stations from Uruguay and Argentina.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
area typo in SEC data?
|Total spot count:||9||0|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2005.12||90.7||41.2||(22.8 predicted, -2.1)|
|2006.01||83.4||15.4||(20.1 predicted, -2.7)|
|2006.02||76.5||4.7||(17.1 predicted, -3.0)|
|2006.03||75.4||10.8||(15.1 predicted, -2.0)|
|2006.04||89.0||30.2||(14.4 predicted, -0.7)|
|2006.05||80.9||22.2||(13.5 predicted, -0.9)|
|2006.06||75.9 (1)||18.7 (2)||(11.4 predicted, -2.1)|
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
