Solar Terrestrial Activity Report

Last major update issued on June 1, 2006 at 04:25 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update April 1, 2006)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update April 1, 2006)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update April 1, 2006)]
[Historical solar and geomagnetic data charts 1954-2005 (last update March 3, 2006)]
[Archived reports (last update May 3, 2006)]

Recent activity

The geomagnetic field was quiet to unsettled on May 31. Solar wind speed ranged between 312 and 426 (all day average 351) km/sec, slowly increasing all day.

Solar flux measured at 20h UTC on 2.8 GHz was 78.4. The planetary A index was 6 (STAR Ap - based on the mean of three hour interval ap indices: 6.0).
Three hour interval K indices: 32111112 (planetary), 32101212 (Boulder).

The background x-ray flux is at the class A2 level.

At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10886 was quiet and stable.

Coronal mass ejections (CMEs)

May 29-31: No partly or fully Earth directed CMEs were observed in LASCO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent trans equatorial coronal hole (CH226) was in an Earth facing position on May 29-30. Another recurrent coronal hole (CH227) in the northern hemisphere will probably rotate into an Earth facing position on June 4-6.

Processed SOHO/EIT 284 image at 19:06 UTC on May 26. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to active on June 1-3 due to a high speed stream from CH226.

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is good. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Radio Cristal del Uruguay had a strong signal tonight. A large number of stations from Argentina, Uruguay and Brazil were heard on other frequencies from 580 to 1690 kHz. The most impressive signals were those of 910 La Red and 1270 Radio Provincia, both Argentina. 1510 kHz was a mess with stations from all 3 countries mentioned above as well as an occasionally fair signal from WWZN.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Monthly solar cycle data

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
