The geomagnetic field was very quiet on August 31. Solar wind speed ranged between 324 and 365 km/s.
Solar flux measured at 20h UTC on 2.8 GHz was 109.0 (decreasing 7.3 over the last solar rotation). The planetary A index was 2 (STAR Ap - based on the mean of three hour interval ap indices: 2.4). Three hour interval K indices: 00101101 (planetary), 10102221 (Boulder).
The background x-ray flux is at the class B3 level.
At midnight UTC the visible solar disk had 10 spotted regions (in 2K resolution SDO images).
Region 11274 decayed slowly and quietly. The region will rotate to the
northwest limb today.
Region 11277 was quiet and stable.
Region 11279 was quiet and stable.
Region 11280 developed with new flux emerging in the southern part of the
region.
Region 11281 developed further with a weak magnetic delta structure
forming in the central penumbra. C flares are possible and there's a slight
chance of an M class flare.
Region 11282 developed further adding many spots. C flares are possible.
Region 11283 developed with penumbra forming on the trailing spots. C
flares are possible, maybe even a minor M class flare.
Flare: C2.2 at 11:24 UTC
Region 11284 developed slowly and could produce a C class flare before
rotating over the southwest limb.
New region 11285 emerged in the northwest quadrant on August 29 and was
noticed by SWPC 2 days later. The region decayed slowly on August 31.
Spotted regions not numbered by NOAA/SWPC:
[S1191] emerged in the northeast quadrant on August 31. Location at midnight:
N25E04
August 29-31: No obviously Earth directed CMEs were observed in LASCO or STEREO imagery.
Coronal hole history (since late October
2002)
Compare today's report to the situation one solar rotation ago:
28 days ago
27 days ago
26 days ago
A coronal hole (CH474) in the southern hemisphere will likely rotate into an Earth facing position on September 1.
The above coronal hole map is based on a new method where coronal holes are detected automatically. The method may need some fine tuning, however, it has significant advantages over detecting coronal holes manually. The main improvement is the ability to detect coronal holes at and just beyond the solar limbs. Early results using this method for SDO images over a span of several weeks indicate a good match between coronal holes observed over the visible disk and their extent and position at the east and west limbs. Note that the polar coronal holes are easily detected using the new method, the extent and intensity of both holes are consistent with other data sources.
Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is fair to good. Propagation on long distance northeast-southwest paths is poor.
The geomagnetic field is expected to be quiet on September 1-3. Quiet to unsettled conditions are possible on September 4-5 due to effects from CH474.
| Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth within the
next 5 days. When the high speed stream has arrived the color changes to
green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48
hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
(Click on image for higher resolution image) Compare to the previous day's image
When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue (blue-green) is positive.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.
| Active region | Date numbered detected |
Spot count | Location at midnight | Area | Classification | SDO / HMI 4K continuum image with polarity overlay |
Comment | |||
|---|---|---|---|---|---|---|---|---|---|---|
| SWPC | STAR SDO | SWPC | STAR | Current | Previous | |||||
| 11274 | 2011.08.19 2011.08.20 |
1 | 1 | N19W72 | 0030 | HRX | AXX |
 |
 |
area: 0000 location: N18W75 |
| 11275 | 2011.08.20 2011.08.21 |
N07W70 |
 |
location: N07W60 plage |
||||||
| 11277 | 2011.08.24 2011.08.25 |
1 | 6 | N18W14 | 0060 | HSX | CSO |
 |
 |
location: N18W13 |
| 11280 | 2011.08.24 2011.08.25 |
2 | 10 | N12W37 | 0010 | CRO | CRO |
 |
 |
area: 0030 |
| 11279 | 2011.08.25 | 1 | 10 | N13W06 | 0080 | HSX | CSO |
 |
 |
area: 0100 |
| 11284 | 2011.08.25 2011.08.30 |
3 | 5 | S17W62 | 0010 | BXO | DRO |
 |
 |
area: 0030 location: S18W73 |
| 11281 | 2011.08.27 2011.08.28 |
11 | 28 | S20E28 | 0100 | DSI | DAI |
 |
 |
beta-gamma-delta location: S21E24 area: 0140 |
| S1185 | 2011.08.28 | N18W24 | plage | |||||||
| 11283 | 2011.08.29 2011.08.30 |
2 | 10 | N12E61 | 0100 | CSO | DSI |
 |
 |
location: N13E65 |
| 11282 | 2011.08.29 2011.08.30 |
9 | 28 | N25W13 | 0050 | DSO | DSI |
 |
 |
area: 0110 |
| S1188 | 2011.08.29 | S26W39 | plage | |||||||
| 11285 | 2011.08.29 2011.08.31 |
1 | 1 | N29W48 | 0010 | AXX | AXX |
 |
 |
formerly region S1189 area: 0000 location: N30W47 |
| S1190 | 2011.08.30 | S13E35 |
 |
plage | ||||||
| S1191 | 2011.08.31 | 2 | N25E04 | 0000 | AXX |
 |
||||
| Total spot count: | 31 | 101 | ||||||||
| Sunspot number: | 121 | 201 | (total spot count + 10 * number of spotted regions) | |||||||
| Classification adjusted SN: | 62 | 132 | (Sum of total spot count + classification adjustment for each AR. Classification adjustment: X=0, R=3, A/S=5, H/K=10) | |||||||
| Relative sunspot number (Wolf number): | 73 | 66 | k * (sunspot number). k = 0.6 for SWPC. k = 0.33 for STAR SDO | |||||||
| Month | Average measured solar flux | International sunspot number (SIDC) | Smoothed sunspot number | Average ap (3) |
|---|---|---|---|---|
| 2008.07 | 65.7 (SF minimum) | 0.5 | 2.8 (-0.4) | |
| 2008.12 | 69.2 | 0.8 | 1.7 (-) sunspot minimum |
3.25 |
| 2010.05 | 73.8 | 8.7 | 15.5 (+1.5) | 9.18 / 8.15 |
| 2010.06 | 72.5 | 13.6 | 16.4 (+0.9) | 8.17 / 6.85 |
| 2010.07 | 79.8 | 16.1 | 16.7 (+0.3) | 6.31 / 5.15 |
| 2010.08 | 79.2 | 19.6 | 17.4 (+0.7) | 8.49 / 7.77 |
| 2010.09 | 81.1 | 25.2 | 19.6 (+2.2) | 5.33 / 5.45 |
| 2010.10 | 81.6 | 23.5 | 23.2 (+3.6) | 6.07 / 6.27 |
| 2010.11 | 82.5 | 21.5 | 26.5 (+3.3) | 4.80 / 5.50 |
| 2010.12 | 84.2 | 14.4 | 28.8 (+2.3) | 3.41 / 4.35 |
| 2011.01 | 83.6 | 19.1 | 31.0 (+2.2) | 4.32 / 5.51 |
| 2011.02 | 94.6 | 29.4 | (33.6 predicted, +2.6) | 5.41 / 6.44 |
| 2011.03 | 115.0 | 56.2 | (36.6 predicted, +3.0) | 7.79 / 8.18 |
| 2011.04 | 112.6 | 54.4 | (39.4 predicted, +2.8) | 9.71 / 8.83 |
| 2011.05 | 95.8 | 41.6 | (42.7 predicted, +3.3) | 9.18 / 8.94 |
| 2011.06 | 95.8 | 37.0 | (46.5 predicted, +3.8) | 8.96 |
| 2011.07 | 94.2 | 43.9 | (50.6 predicted, +4.1) | 9.14 |
| 2011.08 | 101.7 (1) | 66.0 (2A / 2B) [Wolf number: 39.6] | (54.8 predicted, +4.2) | (8.16) |
1) Running average based on the daily 20:00 UTC observed solar flux value at
2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder
(NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The
official SIDC international sunspot number is typically 30-50% lower. 2B) Month
average to date.
3) Running average based on the preliminary daily SWPC ap indices.
Values in red are based on the official NGDC
ap indices.
This report has been prepared by Jan Alvestad. It is based on analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.
SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
