The geomagnetic field was quiet on July 17. Solar wind speed ranged between 335 and 377 km/s. A high speed stream from the northern part of CH466 was observed starting at ACE near 03h UTC on July 18.
Solar flux measured at 20h UTC on 2.8 GHz was 103.6 (increasing 7.2 over the last solar rotation). The planetary A index was 5 (STAR Ap - based on the mean of three hour interval ap indices: 5.1). Three hour interval K indices: 12011122 (planetary), 12021122 (Boulder).
The background x-ray flux is at the class B2 level.
At midnight UTC the visible solar disk had 11 spotted regions.
Region 11245 decayed slowly and quietly. The region will rotate over
the northwest limb today.
Region 11250 was quiet and stable.
Region 11251 was quiet and stable.
Region 11252 was quiet and stable.
Region 11254 developed slowly and was quiet.
Region 11255 was quiet and stable.
Region 11256 developed slowly and was quiet.
New region 11257 first emerged on July 10, became spotless, then
reemerged with spots on July 15 and was numbered by SWPC 2 days later. The
region developed quickly on July 17 and could produce C flares.
Spotted regions not numbered by NOAA/SWPC:
[S1120] emerged in the northeast quadrant on July 15. Location at midnight:
N12W24
[S1122] rotated into view at the northeast limb on July 17. Location at midnight:
N24E83
[S1123] emerged in the northeast quadrant on July 17. Location at
midnight: N06E32
July 15-17: No obviously earth directed CMEs were observed.
Coronal hole history (since late October
2002)
Compare today's report to the situation one solar rotation ago:
28 days ago
27 days ago
26 days ago
A large trans equatorial coronal hole (CH466) was Earth facing on July 14-18.
The above coronal hole map is based on a new method where coronal holes are detected automatically. The method may need some fine tuning, however, it has significant advantages over detecting coronal holes manually. The main improvement is the ability to detect coronal holes at and just beyond the solar limbs. Early results using this method for SDO images over a span of several weeks indicate a good match between coronal holes observed over the visible disk and their extent and position at the east and west limbs. Note that the polar coronal holes are easily detected using the new method, the extent and intensity of both holes are consistent with other data sources.
Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor to fair.
The geomagnetic field is expected to be quiet to active on July 18 and unsettled to minor storm on July 19-20 due to a high speed stream from CH466. Quiet to unsettled conditions are likely on July 20-21.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth within the
next 5 days. When the high speed stream has arrived the color changes to
green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48
hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
(Click on image for higher resolution image) Compare to the previous day's image
When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue (blue-green) is positive.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.
Active region | Date numbered detected |
Spot count | Location at midnight | Area | Classification | SDO / HMI 4K continuum image with polarity overlay |
Comment | |||
---|---|---|---|---|---|---|---|---|---|---|
SWPC | STAR SDO | SWPC | STAR | Current | Previous | |||||
11245 | 2011.07.06 2011.07.07 |
1 | N14W79 | 0000 | AXX | locaton: N17W79 | ||||
11250 | 2011.07.10 | 4 | 5 | S26W48 | 0070 | CSO | HSX | |||
11251 | 2011.07.10 2011.07.11 |
3 | 9 | N16W08 | 0080 | HSX | CSO | area: 0130 |
||
11257 | 2011.07.10 2011.07.17 |
12 | 18 | N19W56 | 0050 | DAI | DAI | formerly region S1108 area: 0200 location: N21W57 |
||
S1110 | 2011.07.10 | S28W59 | plage | |||||||
S1112 | 2011.07.11 | N06W31 | plage | |||||||
11255 | 2011.07.12 2011.07.14 |
3 | 9 | N18E07 | 0010 | BXO | BXO | |||
11252 | 2011.07.12 2011.07.13 |
4 | N25E19 | 0000 | BXO |
|
||||
S1115 | 2011.07.12 | N16W43 | plage | |||||||
11254 | 2011.07.13 2011.07.14 |
15 | 24 | S23E23 | 0050 | CAI | CAI | location: S23E25 |
||
11253 | 2011.07.13 | N14W68 | plage | |||||||
11256 | 2011.07.14 2011.07.15 |
4 | 6 | N08E08 | 0020 | DRO | DRO |
|
||
S1120 | 2011.07.15 | 1 | N12W24 | 0000 | AXX | |||||
S1121 | 2011.07.16 | N18E31 | plage | |||||||
S1122 | 2011.07.17 | 5 | N24E83 | 0040 | CAO | |||||
S1123 | 2011.07.17 | 1 | N06E32 | 0000 | AXX | |||||
Total spot count: | 41 | 83 | ||||||||
Sunspot number: | 101 | 193 | (raw spot count + 10 * number of spotted regions) | |||||||
Classification adjusted SN: | 64 | 111 | (Sum of raw spot count + classification adjustment for each AR. Classification adjustment: X=0, R=3, A/S=5, H/K=10) | |||||||
Relative sunspot number (Wolf number): | 61 | 64 | k * (sunspot number). K = 0.6 for SWPC. K = 0.33 for STAR SDO |
Month | Average measured solar flux | International sunspot number (SIDC) | Smoothed sunspot number | Average ap (3) |
---|---|---|---|---|
2008.07 | 65.7 (SF minimum) | 0.5 | 2.8 (-0.4) | |
2008.12 | 69.2 | 0.8 | 1.7 (-) sunspot minimum |
3.25 |
2010.04 | 75.9 | 8.0 | 14.0 (+1.7) | 10.22 / 10.24 |
2010.05 | 73.8 | 8.7 | 15.5 (+1.5) | 9.18 / 8.15 |
2010.06 | 72.5 | 13.6 | 16.4 (+0.9) | 8.17 / 6.85 |
2010.07 | 79.8 | 16.1 | 16.7 (+0.3) | 6.31 / 5.15 |
2010.08 | 79.2 | 19.6 | 17.4 (+0.7) | 8.49 / 7.77 |
2010.09 | 81.1 | 25.2 | 19.6 (+2.2) | 5.33 / 5.45 |
2010.10 | 81.6 | 23.5 | 23.2 (+3.6) | 6.07 / 6.27 |
2010.11 | 82.5 | 21.5 | 26.5 (+3.3) | 4.80 / 5.50 |
2010.12 | 84.2 | 14.4 | 28.8 (+2.3) | 3.41 / 4.35 |
2011.01 | 83.6 | 19.1 | (30.6 predicted, +1.8) | 4.32 / 5.51 |
2011.02 | 94.6 | 29.4 | (32.6 predicted, +2.0) | 5.41 / 6.44 |
2011.03 | 115.0 | 56.2 | (35.2 predicted, +2.6) | 7.79 / 8.18 |
2011.04 | 112.6 | 54.4 | (38.1 predicted, +2.9) | 9.71 / 8.83 |
2011.05 | 95.8 | 41.6 | (41.4 predicted, +3.3) | 9.18 / 8.94 |
2011.06 | 95.8 | 37.0 | (45.2 predicted, +3.8) | 8.96 |
2011.07 | 89.6 (1) | 34.0 (2A) / 62.1| (2B) | (49.4 predicted, +4.1) | (9.01) |
1) Running average based on the daily 20:00 UTC observed solar flux value at
2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder
(NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The
official SIDC international sunspot number is typically 30-50% lower. 2B) Month
average to date.
3) Running average based on the preliminary daily SWPC ap indices.
Values in red are based on the official NGDC
ap indices.
This report has been prepared by Jan Alvestad. It is based on analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.
