Recent activity

The geomagnetic field was unsettled to active on January 21. Solar wind speed ranged between 562 and 717 km/sec under the influence of a strong coronal stream.

Solar flux measured at 20h UTC on 2.8 GHz was 133.6. The planetary A index was 17 (STAR Ap - based on the mean of three hour interval ap indices: 18.0).
Three hour interval K indices: 33343333 (planetary), 33443323 (Boulder).

The background x-ray flux is at the class B4 level.

At midnight there were 10 spotted regions on the visible disk, 1 of which has not yet been numbered by SEC/NOAA. Solar flare activity was moderate. A total of 7 C and 1 M class events were recorded. A long duration C2.9 event peaking at 08:22 likely had its origin in region 10257 at the northwest limb.

Region 10254 decayed slowly and will rotate over the southwest limb today.
Region 10258 was quiet and unchanged.
Region 10259 decayed slowly and lost the leader spots. Flare: C2.0 at 01:34 UTC.
Region 10260 was basically unchanged and could produce further C class flares. Flares: C8.1 at 02:28 (an event occurred simultaneously in region 10267 and it is difficult to be certain which region was the actual source of the C8 event), C4.1 (associated with a weak type II radio sweep) at 05:57, C3.0 at 13:10 and C2.3 at 21:40 UTC.
Region 10263 reemerged with a single small spot.
Region 10266 developed slowly. The positive and negative polarity areas have drifted slowly apart and further development is unlikely unless new flux emerges.
Region 10267 developed slowly and could produce C class flares. Flare: C1.8 at 09:27 UTC.
New region 10268 emerged in the northeast quadrant.
New region 10269 rotated into view at the southeast limb. This is a fairly small region, however, if the current magnetic delta structure persists, further M class flares will be possible. Flare: M1.9 long duration event peaking at 15:26 UTC.

Spotted regions not yet numbered by SEC/NOAA:
[S79] A new region emerged very quickly in the southwest quadrant a few degrees west of region 10263. There is currently a magnetic delta structure in the largest penumbra and C or even minor M class flares are possible. Location at midnight. S14W43.

Comment added at 11:09 UTC on January 22: Some observations during the first half of the day: Region S79 has decayed somewhat and lost its magnetic delta as the main penumbra split into smaller penumbrae. Region 10259 appears to have become spotless. A new region has emerged just north northeast of region 10258. An M1.2/1F flare with an origin in region 10260 was recorded at 04:44 UTC. No LASCO images covering the hours after the event are currently available.

Coronal mass ejections (CMEs)

January 19: No obviously geoeffective CMEs observed.

January 20: A filament eruption in the northeast quadrant began at approximately 19h UTC with its southwesternmost extension reaching nearly to region 10260. A slowly expanding, bright CME was observed over the northeast limb as early as 19:42 UTC in LASCO C3 images. Early on January 21 this CME became a partial halo CME as it extended south of the equator at the east limb and into the northwest limb. The CME is probably not geoeffective.

January 21: A large CME was observed off of the southeast limb after the M1.9 event in region 10269. The CME is unlikely to be geoeffective.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A huge trans equatorial extension of the southern polar coronal hole was in a geoeffective position on January 16-23.

Processed SOHO EIT 284 image at 01:06 UTC on January 22. Any black areas on the solar disk are likely coronal holes.


The geomagnetic field is expected to be unsettled to minor storm until January 26 due to a coronal stream. Long distance medium wave (AM) band propagation along east-west paths over high and upper middle latitudes is poor to very poor.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions (Recent map)

Composite image based on a SOHO/MDI continuum image and overlaid by a coronal hole image. Region numbering has been included. Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by SEC/NOAA. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots.

Solar region Date numbered SEC
Location at midnight Area Classification Comment
10254 2003.01.10 1 1 S14W77 0100 HSX area was 0070
at midnight
10256 2003.01.12     S16W65     plage
10257 2003.01.13 2   N16W88 0080 DAO strange observation by
SEC/NOAA, the region
had a single small spot
(area 0020) early in the
day and became
spotless during the
10258 2003.01.14 1 1 N07W41 0050 HSX classification was HAX
at midnight, area 0070
10259 2003.01.14 4 3 N10W28 0020 CRO the location was
N11W24 at midnight
10260 2003.01.15 10 13 N14W00 0070 DAO beta-gamma
10261 2003.01.19 3   N26W73 0040 DAO now spotless. Again a
strange observation by
SEC/NOAA. This was at
best a BXO region early
in the day with and area
of 0010.
10262 2003.01.19 1   S05W73 0010 AXX became spotless on
January 20
10263 2003.01.19 4 1 S13W37
0050 CAO location corrected
SEC has apparently
merged two distinctly
separate regions
(see S79).
classification was AXX
at midnight, area 0000
10264 2003.01.20     S20W15     plage
10265 2003.01.20     N04E18     plage
10266 2003.01.20 9 10 S23E43 0100 DAO
10267 2003.01.20 5 5 S20E64 0120 CAO
10268 2003.01.21 3 7 N12E23 0070 CAO classification was DAO
at midnight, area 0040
10269 2003.01.21 4 7 S09E76 0060 HAX beta-delta
classification was DAO
at midnight, area 0120
S79 emerged on
  12 S14W43 0080 DAO beta-delta
Total spot count: 47 60
SSN: 167 160

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2002.01 226.6 114.1 113.5 (-1.1)
2002.02 205.0 107.4 114.6 (+1.2)
2002.03 179.5 98.4 113.3 (-1.3)
2002.04 189.8 120.7 110.5 (-2.9)
2002.05 178.4 120.8 108.8 (-1.7)
2002.06 148.7 88.3 106.2 (-2.6)
2002.07 173.5 99.6 (102.1 predicted, -4.1)
2002.08 183.6 116.4 (98.5 predicted, -3.6)
2002.09 175.8 109.6 (95.5 predicted, -3.0)
2002.10 167.0 97.5 (92.0 predicted, -3.5)
2002.11 168.7 95.0 (86.7 predicted, -5.3)
2002.12 157.2 81.6 (82.4 predicted, -4.3)
2003.01 152.4 (1) 108.7 (2) (79.4 predicted, -3.0)

1) Running average based on the daily 20:00 UT observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (SEC/NOAA) sunspot number. The official international sunspot number is typically 25-45% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and interpretations, and partly on data from sources noted in solar links. All time references are to the UTC day. Comments and suggestions are always welcome.
