Recent activity

The geomagnetic field was quiet to active on December 17. Solar wind speed ranged between 538 and 661 km/sec under the influence of a high speed stream from coronal hole CH133.

Solar flux measured at 20h UTC on 2.8 GHz was 89.9. The planetary A index was 15 (STAR Ap - based on the mean of three hour interval ap indices: 15.0).
Three hour interval K indices: 34332323 (planetary), 35432322 (Boulder).

The background x-ray flux is at the class B1 level.

At midnight there were 4 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10710 was quiet and stable.
New region 10712 emerged in the southeast quadrant.
New region 10713 rotated into view at the southeast limb.

Spotted active regions not numbered by NOAA/SEC:
[S489] This region emerged early in the day just to the east of region 10710. Unfortunately SEC/USAF did not manage to separate this emerging bipolar region from the stable bipolar region 10710.

Coronal mass ejections (CMEs)

December 15-17: No obviously Earth directed CMEs observed. A full halo CME was observed in LASCO C3 images after 19h UTC on December 15. Its source was likely a few days behind the northwest limb.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

An extension (CH133) of the northern polar coronal hole was in a geoeffective position on December 13-14. A recurrent coronal hole (CH134) in the southern hemisphere will likely rotate into a geoeffective position on December 18.

Processed SOHO/EIT 284 image at 18:03 UTC on December 11. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to active on December 18 under the influence of a coronal hole flow and quiet on December 19-20. Another and weaker coronal hole flow could arrive on December 21 or 22 and cause some unsettled and active intervals.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor (approaching poor to fair). Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: Radio Vibración (Venezuela) and WLAM Lewiston ME. Several stations from the easternmost parts of North America could be heard on other frequencies with the best signals above 1400 kHz.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10710 2004.12.08 5 3 S07W72 0050 EAI classification was DAO
at midnight
location S07W79
see region S489
10712 2004.12.17 4 5 S10E50 0020 DSO
10713 2004.12.17 1 2 S10E70 0070 HAX
S488 emerged on
2004.12.13
    S15W12     plage
S489 emerged on
2004.12.17
  2 S09W69 0030 CSO
Total spot count: 10 12
SSN: 40 52

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.10 151.7 65.5 58.2 (-1.3)
2003.11 140.8 67.3 56.7 (-1.5)
2003.12 114.9 46.5 54.8 (-1.9)
2004.01 114.1 37.3 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 47.1 (-2.2)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.9 (-1.6)
2004.06 97.4 43.2 (42.2 predicted, -1.7)
2004.07 119.1 51.0 (40.6 predicted, -1.6)
2004.08 109.6 40.9 (39.0 predicted, -1.6)
2004.09 103.1 27.7 (37.1 predicted, -1.9)
2004.10 105.9 48.4 (34.9 predicted, -2.2)
2004.11 113.2 43.7 (33.0 predicted, -1.9)
2004.12 92.6 (1) 20.1 (2) (30.7 predicted, -2.3)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
