Solar Terrestrial Activity Report

Last major update issued on January 1, 2005 at 06:30 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update December 3, 2004)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update December 3, 2004)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update December 3, 2004)]
[Historical solar and geomagnetic data charts 1954-2004 (last update November 8, 2004)]
[Archived reports (last update December 24, 2004)]

Recent activity

The geomagnetic field was quiet to unsettled on December 31. Solar wind speed ranged between 426 and 491 km/sec.

Solar flux measured at 20h UTC on 2.8 GHz was 98.5. The planetary A index was 8 (STAR Ap - based on the mean of three hour interval ap indices: 7.6).
Three hour interval K indices: 31323211 (planetary), 22323321 (Boulder).

The background x-ray flux is at the class B2 level.

At midnight there were 3 spotted regions on the visible solar disk. The solar flare activity level was moderate. A total of 4 C and 1 M class events were recorded during the day. Solar activity became high a few minutes into the new year as region 10715 produced a major X1.7 flare (which began at 00:23 and peaked at 00:31 UTC). This event was preceded by a C1.5 flare (which began at 00:01 and peaked at 00:11 UTC) in the same region.

Region 10715 decayed and lost about a quarter of its penumbral area. The region is still complex, however, the magnetic delta structure in the center of the region has become less obvious. Flares: C1.2 at 00:43, C5.7 long duration event peaking at 04:44, C2.0 at 06:42, M1.2 at 14:45 and C6.8 at 14:59 UTC.
Region 10716 developed slowly and quietly.
New region 10717 emerged in the northwest quadrant.

Coronal mass ejections (CMEs)

January 1: A large, fast, partially Earth directed CME is likely to have been associated with the X1.7 event early in the day and could reach Earth late on January 2 or early on January 3.
December 31
: No obvious Earth directed CMEs were observed during the first 16 hours of the day.
December 30
: A full halo CME was observed after the M2.2 event in region 10715 before noon. The CME was faint over the poles and the west limbs. Another, larger and faster, CME was observed after the M4 event in region 10715 late in the day. Although the cores of these CMEs won't reach Earth, the flanking impacts are likely to cause minor geomagnetic disturbances on January 1 or 2.
December 29
: The CME associated with the M2.3 flare in region 10715 was well defined over the east limb, very faint extensions were observed around the remainder of the disk.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A poorly defined extension (CH137) of a coronal hole in the northern hemisphere was in a possibly geoeffective position on December 29. Recurrent trans equatorial coronal hole CH136 was in a geoeffective position on December 31-January 1.

Processed SOHO/EIT 284 image at 01:06 UTC on December 31. The darkest areas on the solar disk are likely coronal holes.


The geomagnetic field is expected to be quiet to active on January 1 and unsettled to minor storm on January 2-3 due to CMEs and coronal hole effects.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.


Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: Radio Vibración and WLAM Lewiston, both with weak signals. Most of the other trans Atlantic signals noted were from the Canadian Atlantic provinces and the northeastern USA.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
Location at midnight Area Classification Comment
10715 2004.12.28 22 14 N04E34 0220 DAC beta-gamma
classification was DSC
at midnight
10716 2004.12.30 5 4 S14E37 0020 CAO
10717 2004.12.31 3 1 N07W56 0010 CAO classification was HSX
at midnight
S491 emerged on
    S16W50     plage
Total spot count: 30 19
SSN: 60 49

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.10 151.7 65.5 58.2 (-1.3)
2003.11 140.8 67.3 56.7 (-1.5)
2003.12 114.9 46.5 54.8 (-1.9)
2004.01 114.1 37.3 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 47.1 (-2.2)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.9 (-1.6)
2004.06 97.4 43.2 (42.2 predicted, -1.7)
2004.07 119.1 51.0 (40.6 predicted, -1.6)
2004.08 109.6 40.9 (39.0 predicted, -1.6)
2004.09 103.1 27.7 (37.1 predicted, -1.9)
2004.10 105.9 48.4 (34.9 predicted, -2.2)
2004.11 113.2 43.7 (33.0 predicted, -1.9)
2004.12 94.5 (1) 34.9 (2) (30.7 predicted, -2.3)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
