Last major update issued on February 17, 2005 at 07:10 UTC.
geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update January 2, 2005)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update January 2, 2005)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update January 2, 2005)]
[Historical solar and geomagnetic data charts 1954-2004 (last update February 1, 2005)]
[Archived reports (last update February 16, 2005)]
The geomagnetic field was quiet to active on February 16.
speed ranged between 368 and 470 km/sec under the influence of a low to
moderately high speed stream from CH145.
Solar flux measured at 20h UTC on 2.8 GHz was 113.8. The planetary
index was 13 (STAR Ap - based on the mean of three hour interval ap
Three hour interval K indices: 21244333 (planetary), 22234333 (Boulder).
The background x-ray flux is at the class B2 level.
At midnight there were 4 spotted regions on the visible solar disk. The solar flare activity level was low. A total of 2 C class events was recorded during the day.Region 10733 decayed slowly and quietly.
Spotted regions not numbered by NOAA/SEC:
[S513] This region emerged to the northwest of region 10735 on February 15. Decay was observed on February 16 and the region could soon become spotless. Location at midnight: S04W10.
February 14-16: No obvious fully or partly Earth directed CMEs were observed.
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
A recurrent coronal hole (CH145) in the northern hemisphere was in a geoeffective position on February 13-15.
Processed SOHO/EIT 284 image at 01:06 UTC on February 17. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to active on February
17-18 due to effects from CH145 and quiet to unsettled on February
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation
east-west paths over high and upper middle latitudes is poor.
Propagation along long distance north-south paths is poor.
Atlantic propagation conditions are normally monitored every night on
1470 kHz. Dominant station tonight: Radio Vibración (Venezuela).
No North American stations were observed at 02h UTC, however, at
0430 UTC both WWZN on 1510 and WWRU on 1660 had fair signals.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
|Total spot count:||31
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2004.08||109.6||40.9||(38.9 predicted, -1.4)|
|2004.09||103.1||27.7||(36.6 predicted, -2.3)|
|2004.10||105.9||48.4||(34.4 predicted, -2.2)|
|2004.11||113.2||43.7||(32.5 predicted, -1.9)|
|2004.12||94.5||17.9||(30.2 predicted, -2.3)|
|2005.01||102.2||31.3||(27.6 predicted, -2.6)|
|2005.02||102.8 (1)||30.7 (2)||(25.2 predicted, -2.4)|
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
