Recent activity

The geomagnetic field was unsettled to severe storm on January 17. Solar wind speed ranged between 512 and 861 km/sec. ACE data indicated abnormal solar wind conditions at 07:17 UTC when solar wind speed increased abruptly from 530 to 610 km/sec. The total field of the interplanetary magnetic field became suddenly stronger as well. The source of this solar wind abnormality was probably the arrival of the halo CME observed after an M8 event in region 10720 on January 15. Another interesting change occurred at about 10:42 UTC when the IMF again had a sudden increase in its total field. The most likely source for this change was the arrival of the CME associated with an X2 flare in region 10720 late on January 15. With both CMEs arriving at a time when solar wind speed was already high, there were no true shocks (SOHO data did indicate a sudden increase in solar wind density at the time of the first abnormality, however, this increase was not present in ACE data. Based on data from both SOHO and ACE one could say this was a solar wind shock). Severe geomagnetic storming was observed after the second abnormality.

Solar flux measured at 20h UTC on 2.8 GHz was 137.2. The planetary A index was 63 (STAR Ap - based on the mean of three hour interval ap indices: 62.8).
Three hour interval K indices: 54377753 (planetary), 44366653 (Boulder).

The background x-ray flux is at the class C1 level.

At midnight there were 4 spotted regions on the visible solar disk. The solar flare activity level was high. A total of 4 C. 2 M and 1 X class events was recorded during the day.

Region 10718 decayed further and was quiet.
Region 10720 lost some penumbral area and a few spots after the X3 event. While there are still several magnetic delta structures in the region, the only one of particular interest is the extremely strong delta in the center of the huge penumbra. The opposite polarity umbrae are very large and do not have that much separation. Very energetic X class flares are still likely with an increasing chance of a huge proton event as the region moves into a more favorable position for proton events. Flares: C3.9 at 02:59, M2.6 at 03:21, C3.9 at 06:10, M1.8 at 06:58, major X3.8/2F long duration proton event peaking at 09:52 (associated with a strong type II and a moderate type IV radio sweep), C4.8 at 19:50 and C3.1 at 22:42 UTC.
New region 10723 rotated into view at the northeast limb on January 17.

Spotted regions not numbered by NOAA/SEC:
S498: This region emerged in the southeast quadrant on January 16. Location at midnight: S11E05

Coronal mass ejections (CMEs)

January 16: No obvious fully or partly Earth directed CMEs were observed.
January 17
: A large and fast full halo CME was observed after the X3 event in region 10720 during the UTC morning. This CME will likely reach Earth late on January 18 and cause major to very severe geomagnetic storming.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A fairly large recurrent coronal hole (CH140) in the northern hemisphere will likely rotate to a geoeffective position on January 19-20.

Processed SOHO/EIT 284 image at 20:17 UTC on January 17. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be unsettled to severe or very severe storm on January 18-19 due to CME effects.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is useless due to the the proton storm currently in progress. Propagation along long distance north-south paths is fair. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: none. This was a lively frequency with at least 4 stations from Brazil noted. Additionally Radio Cristal del Uruguay and Radio Vibración (Venezuela) - with Union Radio Noticias programming - were noted at times. On other frequencies propagation was fairly good towards Brazil, particularly on frequencies above 1350 kHz.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10718 2005.01.07 17 7 S07W47 0240 FAI classification was ESO at midnight,
area 0190
10720 2005.01.10 48 42 N13W30 1460  EKC gamma-delta
10721 2005.01.16 1   S03E02 0000 AXX spotless
10722 2005.01.16     N19W09     plage
10723 2005.01.17 1 1 N06E77 0070 HAX
S494 emerged on
2005.01.13

S01W43

plage
S495 visible on
2005.01.13

S06E43

plage
S498 emerged on
2005.01.16
  3 S11E05 0010 AXX
S499 emerged on
2005.01.15
    S05W76     rotated out of view
Total spot count: 67 53
SSN: 107 93

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.11 140.8 67.3 56.7 (-1.5)
2003.12 114.9 46.5 54.8 (-1.9)
2004.01 114.1 37.3 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 47.1 (-2.2)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.9 (-1.6)
2004.06 97.4 43.2 41.7 (-2.2)
2004.07 119.1 51.0 (39.6 predicted, -1.9)
2004.08 109.6 40.9 (38.0 predicted, -1.6)
2004.09 103.1 27.7 (36.1 predicted, -1.9)
2004.10 105.9 48.4 (33.9 predicted, -2.2)
2004.11 113.2 43.7 (32.0 predicted, -1.9)
2004.12 94.5 17.9 (29.7 predicted, -2.3)
2005.01 104.2 (1) 27.7 (2) (27.0 predicted, -2.7)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
