Recent activity

The geomagnetic field was quiet to major storm on May 20. Solar wind speed ranged between 382 and 527 km/sec. The disturbance which began early on May 20 had been preceded by a slowly increasing solar wind density (typical of high speed streams from coronal holes). While there was no obvious solar wind shock, the intensity of the disturbance and the changes in the total field of the interplanetary magnetic field - particularly after noon - indicate that the CME observed on May 17 had merged with the nearly equal speed stream from CH166 and became an increasingly important factor in the solar wind during the day.

Solar flux measured at 20h UTC on 2.8 GHz was 83.5. The planetary A index was 30 (STAR Ap - based on the mean of three hour interval ap indices: 30.3).
Three hour interval K indices: 36644323 (planetary), 35554322 (Boulder).

The background x-ray flux is at the class B1 level.

At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10765 developed slowly during the day and was quiet.

Coronal mass ejections (CMEs)

May 18-20: No obviously fully or partly potentially geoeffective CMEs were observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently in Earth facing positions.

Processed SOHO/EIT 284 image at 11:36 UTC on May 20. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to minor storm on May 21 and quiet to unsettled on May 22-24.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Cristal del Uruguay. Only a few stations from mainly Brazil were noted on other trans Atlantic frequencies.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10759 2005.05.08 1   N12W88 0150 HAX rotated out of view
10763 2005.05.12     S16W48     plage
10765 2005.05.19 1 2 N09E51 0020 HSX
S548 2005.05.17     S13W27     plage
S549 2005.05.18     S12W34     plage
Total spot count: 2 2
SSN: 22 12

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2004.03 112.0 49.1 47.1 (-2.2)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.8 (-1.7)
2004.06 97.4 43.2 41.6 (-2.2)
2004.07 119.1 51.1 40.2 (-1.4)
2004.08 109.6 40.9 39.2 (-1.0)
2004.09 103.1 27.7 37.5 (-1.7)
2004.10 105.9 48.0 35.9 (-1.6)
2004.11 113.2 43.5 (34.8 predicted, -1.1)
2004.12 94.5 17.9 (33.4 predicted, -1.4)
2005.01 102.2 31.3 (30.9 predicted, -2.5)
2005.02 97.2 29.1 (28.3 predicted, -2.6)
2005.03 89.9 24.8 (26.5 predicted, -1.8)
2005.04 86.0 24.4 (24.6 predicted, -1.9)
2005.05 105.1 (1) 45.9 (2) (22.0 predicted, -2.6)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
