Last major update issued on October 6, 2005 at 03:05 UTC. The next update will likely be on October 15 (see http://www.kongsfjord.no)
[Solar and
geomagnetic data - last month (updated daily)]
[Solar wind and
electron fluence charts (updated daily)]
[Solar cycles 21-23
(last update October 2, 2005)]
[Solar cycles 1-20]
[Graphical comparison
of cycles 21, 22 and 23 (last update October 2, 2005)]
[Graphical
comparison of cycles 2, 10, 13, 17, 20 and 23 (last update October 2,
2005)]
[Historical solar and
geomagnetic data charts 1954-2004 (last update February 1, 2005)]
[Archived reports
(last update October 2, 2005)]
The geomagnetic field was inactive to quiet on October 5. Solar wind speed ranged between 285 and 316 (all day average 297) km/sec.
Solar flux measured at 20h UTC on 2.8 GHz was 81.3. The planetary
A
index was 4 (STAR Ap - based on the mean of three hour interval ap
indices: 4.1).
Three hour interval K indices: 01101121 (planetary), 00202211 (Boulder).
The background x-ray flux is at the class B1 level.
At midnight there was one spotted region on the visible solar disk. The solar flare activity level was low. A single C class event was recorded during the day.
Region 10813 decayed, particularly in the southern section. The separation between the opposite polarity areas have become better defined and the flare potential has decreased. Flare: C1.4 at 08:22 UTC.
October 3-5: No obvious fully or partly Earth directed CMEs were observed.
Coronal hole
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28
days ago 27 days ago 26
days ago
A recurrent trans equatorial coronal hole (CH191) will rotate to an Earth facing position on October 5-7.
Processed SOHO/EIT 284 image at 19:06 UTC on October 5. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be mostly quiet October 6-7. A high speed stream from CH191 will likely arrive during the latter half of October 8 and cause unsettled to minor storm conditions until October 10. Quiet to unsettled is likely on October 11-13.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next
48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is good. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: WLAM Lewiston ME and WWNN Boca Raton FL. Propagation was mostly unchanged from the day before with lots of strong signals from North American stations throughout the MW band, from CBT on 540 to presumed WJCC (and another unidentified station) on 1700 kHz.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
Active region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
10813 | 2005.10.04 | 21 | 23 | S08E18 | 0160 | DAC | classification was DAO at midnight |
S595 | 2005.09.30 | N12W80 | plage | ||||
S596 | 2005.10.02 | S10W81 | plage | ||||
Total spot count: | 21 | 23 | |||||
SSN: | 31 | 33 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2004.08 | 109.6 | 40.9 | 39.2 (-1.0) |
2004.09 | 103.1 | 27.7 | 37.5 (-1.7) |
2004.10 | 105.9 | 48.0 | 35.9 (-1.6) |
2004.11 | 113.2 | 43.5 | 35.3 (-0.6) |
2004.12 | 94.5 | 17.9 | 35.2 (-0.1) |
2005.01 | 102.2 | 31.3 | 34.6 (-0.6) |
2005.02 | 97.2 | 29.2 | 33.9 (-0.7) |
2005.03 | 89.9 | 24.5 | 33.5 (-0.4) |
2005.04 | 86.0 | 24.4 | (31.9 predicted, -1.6) |
2005.05 | 99.3 | 42.6 | (29.4 predicted, -2.5) |
2005.06 | 93.7 | 39.6 | (28.1 predicted, -1.3) |
2005.07 | 96.4 | 39.9 | (26.9 predicted, -1.2) |
2005.08 | 90.5 | 36.4 | (25.0 predicted, -1.9) |
2005.09 | 91.1 | 22.1 | (23.0 predicted, -2.0) |
2005.10 | 77.1 (1) | 1.5 (2) | (21.0 predicted, -2.0) |
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC)
sunspot number. The official international sunspot number is typically
30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
