Solar Terrestrial Activity Report

Last major update issued on July 13, 2006 at 04:30 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update June 7, 2006)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update June 7, 2006)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update June 7, 2006)]
[Historical solar and geomagnetic data charts 1954-2005 (last update March 3, 2006)]
[Archived reports (last update July 9, 2006)]

Recent activity

The geomagnetic field was quiet to active on July 12. Solar wind speed ranged between 425 and 582 km/s (all day average 518 km/s - increasing 135 km/s over the previous day) under the influence of a high speed stream from CH231.

Solar flux measured at 20h UTC on 2.8 GHz was 70.6 (at 23h UTC solar flux was 68.5 - the lowest recorded since the previous solar minimum). The planetary A index was 12 (STAR Ap - based on the mean of three hour interval ap indices: 12.0).
Three hour interval K indices: 32344212 (planetary), 23434312 (Boulder).

The background x-ray flux is below the class A1 level.

At midnight the visible solar disk was spotless. The solar flare activity level was very low. No C class events were recorded during the day.

Coronal mass ejections (CMEs)

July 10-12: No partly or fully Earth directed CMEs were detected in LASCO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently in or approaching Earth facing locations.

Processed SOHO/EIT 284 image at 19:06 UTC on July 12. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on July 13 due to a high speed stream from CH231 and quiet July 14-18.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is poor to fair. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Radio Cristal del Uruguay had a fair signal and little competition from other signals. Otherwise propagation favored Brazil and particularly stations from the São Paulo area.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10899 2006.07.05 2   S05W28 0010 BXO spotless
Total spot count: 2 0
SSN: 12 0

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2005.05 99.3 42.7 28.9 (-2.7)
2005.06 93.7 39.3 28.8 (-0.1)
2005.07 96.4 40.1 29.1 (+0.3)
2005.08 90.5 36.4 27.4 (-1.7)
2005.09 91.1 21.9 25.8 (-1.6)
2005.10 77.0 8.5 25.5 (-0.3)
2005.11 86.3 18.0 24.9 (-0.6)
2005.12 90.7 41.2 23.0 (-1.9)
2006.01 83.4 15.4 (20.7 predicted, -2.3)
2006.02 76.5 4.7 (18.2 predicted, -2.5)
2006.03 75.4 10.8 (16.4 predicted, -1.8)
2006.04 89.0 30.2 (15.7 predicted, -0.7)
2006.05 80.9 22.2 (14.9 predicted, -0.8)
2006.06 76.5 13.9 (12.7 predicted, -2.2)
2006.07 80.2 (1) 11.4 (2) (11.3 predicted, -1.4)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
