Recent activity

The geomagnetic field was inactive to quiet on March 12. Solar wind speed ranged between 447 and 557 (all day average 502) km/sec under the decreasing influence of a high speed stream from CH215.

Solar flux measured at 20h UTC on 2.8 GHz was 73.2. The planetary A index was 6 (STAR Ap - based on the mean of three hour interval ap indices: 5.5).
Three hour interval K indices: 01211221 (planetary), 01222100 (Boulder).

The background x-ray flux is below the class A1 level.

At midnight there was 2 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

New region 10858 emerged quickly in the northeast quadrant.

Spotted regions not numbered by NOAA/SEC:
[S630] This region rotated into view at the southeast limb on March 12. Location at midnight: S03E77.

Coronal mass ejections (CMEs)

March 10-12: No rtly or fully Earth directed CMEs were observed in \LASCO images.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent trans equatorial coronal hole (CH215) appears to have become larger over the last solar rotation and was in an Earth facing position on March 5-7.

Processed SOHO/EIT 284 image at 01:20 UTC on February 28. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet on March 13-15.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: WLAM Lewiston ME with a weak signal.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10857 2006.03.05     N08W54     plage
10858 2006.03.12 8 6 N18E15 0020 CRO classification was DSO at midnight, area 0040
S629 2006.03.06     S15W62     plage
S630 2006.03.12   1 S03E77 0010 HRX plage
Total spot count: 8 7
SSN: 18 27

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2005.01 102.2 31.3 34.6 (-0.6)
2005.02 97.2 29.2 33.9 (-0.7)
2005.03 89.9 24.5 33.5 (-0.4)
2005.04 86.0 24.2 31.6 (-1.9)
2005.05 99.3 42.7 28.9 (-2.7)
2005.06 93.7 39.3 28.8 (-0.1)
2005.07 96.4 40.1 29.1 (+0.3)
2005.08 90.5 36.4 27.4 (-1.7)
2005.09 91.1 21.9 (25.6 predicted, -1.8)
2005.10 77.0 8.5 (23.8 predicted, -1.8)
2005.11 86.3 18.0 (21.4 predicted, -2.4)
2005.12 90.7 41.2 (18.5 predicted, -2.9)
2006.01 83.4 15.4 (15.4 predicted, -3.1)
2006.02 76.5 4.7 (12.3 predicted, -3.1)
2006.03 74.2 (1) 5.1 (2) (10.1 predicted, -2.2)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
