Solar Terrestrial Activity Report

Last major update issued on May 20, 2006 at 04:40 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update April 1, 2006)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update April 1, 2006)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update April 1, 2006)]
[Historical solar and geomagnetic data charts 1954-2005 (last update March 3, 2006)]
[Archived reports (last update May 3, 2006)]

Recent activity

The geomagnetic field was quiet to unsettled on May 19. Solar wind speed ranged between 478 and 566 (all day average 532) km/sec under the influence of a high speed stream from CH225.

Solar flux measured at 20h UTC on 2.8 GHz was 75.3. The planetary A index was 8 (STAR Ap - based on the mean of three hour interval ap indices: 8.0).
Three hour interval K indices: 22301223 (planetary), 12312222 (Boulder).

The background x-ray flux is at the class A2 level.

At midnight there were 2 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

New region 10884 emerged in the southeast quadrant on May 18 and was numbered the next day by NOAA/SEC. The region developed penumbra on both polarities on May 19.

Spotted regions not numbered by NOAA/SEC:
[S654] This region emerged to the east of region 10884 on May 19. Location at midnight: S12E58.

Coronal mass ejections (CMEs)

May 17-19: No partly or fully Earth directed CMEs were observed in LASCO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A coronal hole (CH225) in the southern hemisphere was an Earth facing position on May 16-18.

Processed SOHO/EIT 284 image at 19:06 UTC on May 19. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on May 20-21 due to a high speed stream from CH225 and quiet on May 22-24.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is fair. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Radio Cristal del Uruguay had the dominant signal tonight. Before LSR several stations from Newfoundland and the northeastern USA were heard at poor to fair signal levels with 1510 WWZN coming in well. After LSR quite a few stations from Argentina became audible with the best signals from 1510 Radio Belgrano and 1190 Radio América.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10884 2006.05.19 5 6 S13E47 0020 BXO formerly region S653
classification was DSO at midnight, area 0040
S654 2006.05.19   3 S12E58 0010 CSO
Total spot count: 5 9
SSN: 15 29

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2005.02 97.2 29.2 33.9 (-0.7)
2005.03 89.9 24.5 33.5 (-0.4)
2005.04 86.0 24.2 31.6 (-1.9)
2005.05 99.3 42.7 28.9 (-2.7)
2005.06 93.7 39.3 28.8 (-0.1)
2005.07 96.4 40.1 29.1 (+0.3)
2005.08 90.5 36.4 27.4 (-1.7)
2005.09 91.1 21.9 25.8 (-1.6)
2005.10 77.0 8.5 25.5 (-0.3)
2005.11 86.3 18.0 (24.5 predicted, -1.0)
2005.12 90.7 41.2 (21.8 predicted, -2.7)
2006.01 83.4 15.4 (18.7 predicted, -3.1)
2006.02 76.5 4.7 (15.6 predicted, -3.1)
2006.03 75.4 10.8 (13.4 predicted, -2.2)
2006.04 89.0 30.2 (12.7 predicted, -0.7)
2006.05 80.5 (1) 21.4 (2) (12.2 predicted, -0.5)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
