Recent activity

The geomagnetic field was quiet to active on September 21. Solar wind speed ranged between 400 and 578 km/s (average speed was 462 km/s, increasing 111 km/s over the previous day) under the influence of a high speed stream from CH291.

Solar flux measured at 20h UTC on 2.8 GHz was 66.9. The planetary A index was 9 (STAR Ap - based on the mean of three hour interval ap indices: 8.9). Three hour interval K indices: 22122224 (planetary), 22222224 (Boulder).

The background x-ray flux is below the class A1 level.

At midnight the visible solar disk was spotless (consecutive days: 15). The solar flare activity level was very low. No C class events were recorded during the day.

Coronal mass ejections (CMEs)

September 19-21: No obvious fully or partly Earth directed CMEs were observed in LASCO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A large, recurrent trans equatorial coronal hole (CH291) was in an Earth facing position on September 16-21. A recurrent coronal hole (CH292) in the southern hemisphere could rotate into an Earth facing position on September 25.

Processed SOHO/EIT 195 image at 00:00 UTC on September 22. The darkest areas on the solar disk are likely coronal holes.


Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair. Propagation on long distance northeast-southwest paths is poor to fair.

Monitoring remarks from a location near N58E06: September 22: Stations located in the Canadian Atlantic provinces, the northeastern USA and Florida had fair to good signals. 1420 WBSM was surprisingly strong while 1080 WTPS was up and down with WTIC. Many stations from Cuba had strong signals as well, and a few from the Dominican Republic, like 1240 Radio Maria, did well. In the lower part of the AM band Venezuela was heard on many frequencies. 550 Radio Mundial was very clear and there was an interesting unidentified station on 540 kHz.


The geomagnetic field is expected to be quiet to active on September 22-24 due to a high speed stream from CH291, occasional minor storm intervals are possible. Mostly quiet conditions are likely on September 25-27.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
Location at midnight Area Classification Comment
Total spot count: 0 0
SSN: 0 0

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2006.07 75.7 12.2 15.3 (-1.0)
2006.08 79.0 12.9 15.6 (+0.3)
2006.09 77.8 14.4 15.6 (+0.0)
2006.10 74.3 10.4 14.2 (-1.4)
2006.11 86.3 21.5 12.7 (-1.5)
2006.12 84.5 13.6 12.1 (-0.6)
2007.01 83.3 16.9 12.0 (-0.1)
2007.02 77.7 10.6 11.6 (-0.4)
2007.03 72.2 4.8 (11.1 predicted, -0.5)
2007.04 72.4 3.7 (10.7 predicted, -0.4)
2007.05 74.4 11.7 (10.2 predicted, -0.5)
2007.06 73.7 12.0 (10.0 predicted, -0.2)
2007.07 71.6 10.0 (10.0 predicted, +0.0)
2007.08 69.1 6.2 (10.3 predicted, +0.3)
2007.09 67.2 (1) 3.2 (2) (11.5 predicted, +1.2)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
