The geomagnetic field was quiet to active on May 1. Solar wind speed ranged between 410 and 481 km/s. A disturbance related to CH323 was observed at ACE at 16h UTC.
Solar flux measured at 20h UTC on 2.8 GHz was 68.5. The planetary A index was 9 (STAR Ap - based on the mean of three hour interval ap indices: 9.1). Three hour interval K indices: 01201334 (planetary), 11212324 (Boulder).
The background x-ray flux is below the class A1 level.
At midnight the visible solar disk was spotless. The solar flare activity level was very low.
April 29 - May 1: No partially or fully Earth directed CMEs were observed.
Coronal hole
history (since late October 2002)
Compare today's report to the situation one solar rotation ago:
28
days ago
27
days ago
26
days ago
What used to be recurrent coronal hole (CH319) has decayed during the last solar rotation and fragmented into smaller coronal holes. CH323 was in an Earth facing position on April 28-29. The eastern part of CH319 is now CH324. CH324 is Earth facing on April 30 - May 2.
Processed SOHO/EIT 195 image at 00:24 UTC on May 2. The darkest areas on the solar disk are likely coronal holes.
Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is fair.
The geomagnetic field is expected to be quiet to active on May 2-4 due to coronal hole effects from CH323 and CH324..
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the
color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96
hours.
3) There is a possibility of either M or X class flares within the next
48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.
Active region | Date numbered | SWPC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
S723 | 2008.04.30 | N12W44 | plage | ||||
Total spot count: | 0 | 0 | |||||
SSN: | 0 | 0 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2007.03 | 72.2 | 4.5 | 10.7 (-0.8) |
2007.04 | 72.4 | 3.4 | 9.8 (-0.9) |
2007.05 | 74.4 | 11.7 | 8.6 (-1.2) |
2007.06 | 73.7 | 12.1 | 7.6 (-1.0) |
2007.07 | 71.6 | 9.7 | 6.9 (-0.7) |
2007.08 | 69.1 | 6.0 | 6.0 (-0.9) |
2007.09 | 67.1 | 2.4 | 5.9 (-0.1) |
2007.10 | 67.4 | 0.9 | 6.0 (+0.1) |
2007.11 | 69.6 | 1.7 | (5.7 predicted, -0.3) |
2007.12 | 78.5 | 10.1 | (5.3 predicted, -0.4) |
2008.01 | 74.3 | 3.4 | (5.1 predicted, -0.2) |
2008.02 | 71.1 | 2.1 | (5.4 predicted, +0.3) |
2008.03 | 72.9 | 9.3 | (6.4 predicted, +1.0) |
2008.04 | 70.2 | 2.9 | (7.8 predicted, +1.4) |
2008.05 | 68.5 (1) | 0.0 (2) | (9.6 predicted, +1.8) |
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SWPC) sunspot number. The official international sunspot number is typically
30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
