Recent activity

The geomagnetic field was quiet to minor storm on August 2. Solar wind speed at SOHO ranged between 348 and 455 km/s. The disturbance associated with the CME observed on July 28 arrived just after 10h UTC at ACE.

Solar flux measured at 20h UTC on 2.8 GHz was 134.6 (decreasing 23.1 over the last solar rotation). The Potsdam WDC planetary A index was 19 (STAR Ap - based on the mean of three hour interval ap indices: 19.0). Three hour interval K indices: 11125543 (planetary), 10124533 (Boulder).

The background x-ray flux is at the class B6 level.

At midnight UTC the visible solar disk had 12 spotted active regions (in 2K resolution SDO images).

Region 11528 [N16W69] developed slowly and quietly.
Region 11529 [S11W62] was quiet and stable.
Region 11530 [S19W52] was quiet and stable.
Region 11532 [S21W23] was quiet and stable.
Region 11535 [N18E23] decayed in the trailing spot section and was mostly quiet.
Region 11537 [N12E50] was quiet and stable.
Region 11538 [S23E45] developed in the trailing spot section and has weak polarity intermixing.
New region 11539 [S23E58] rotated into view on August 1 and was numbered the next day by SWPC. This is a reversed polarities group.

Spotted active regions not numbered or interpreted differently by NOAA/SWPC:
New region S1838 [S17E77] rotated into view.
New region S1839 [S27E69] rotated into viw with small spots.
New region S1840 [N09E28] emerged with small spots.
New region S1841 [N07W42] emerged with several spots.

Coronal mass ejections (CMEs)

July 31 - August 2: No obviously Earth directed CMEs were observed in LASCO and STEREO imagery.

Coronal holes

Coronal hole history (since October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently in or close to geoeffective positions.

Coronal hole map

The above coronal hole map is based on a method where coronal holes are detected automatically. While the method may need some fine tuning, it has significant advantages over detecting coronal holes manually. The main improvement is the ability to detect coronal holes at and just beyond the solar limbs. Early results using this method for SDO images over a span of several weeks indicate a good match between coronal holes observed over the visible disk and their extent and position at the east and west limbs. Note that the polar coronal holes are easily detected using this method, the extent and intensity of both CHs are consistent with other data sources.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor to fair.

Forecast

The geomagnetic field is expected to be quiet to unsettled on August 3-5.

Coronal holes (1) Coronal mass ejection (2) M and X class flares (3)


1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions

Click on image for higher resolution image) Compare to the previous day's image

When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue (blue-green) is positive.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered
detected
Spot count Location at midnight Area Classification SDO / HMI 4K continuum
image with magnetic polarity overlay
Comment
SWPC STAR SDO SWPC STAR Current Previous
2K 1K
11528 2012.07.22
2012.07.23
1 5 3 N17W70 0020 HRX DRO



11527 2012.07.22
2012.07.23
      N27W73           plage
11529 2012.07.22
2012.07.23
1 1 1 S11W62 0030 HSX HSX
11530 2012.07.23
2012.07.24
1 2 1 S19W53 0120 HSX CSO

area: 0200

11532 2012.07.25
2012.07.26
5 23 10 S18W28 0230 CSO FHO beta-gamma

area: 0400

location: S21W23

11533 2012.07.26
2012.07.27
      S28W63
11534 2012.07.27
2012.07.28
      N17W15         plage
S1827 2012.07.28       N17W53           plage
11535 2012.07.29
2012.07.30
10 13 7 N17E24 0120 DSO DSO area: 0240
11536 2012.07.30 6     S23W13 0070 EAO       part of AR 11532
S1832 2012.07.30       N21W43           plage
11537 2012.07.31 1 1 1 N12E50 0050 HSX HSX
11538 2012.07.31 7 13 9 S23E43 0220 DAO DKO area: 0450
S1833 2012.07.31       N15W49           plage
S1835 2012.07.31       N12E10           plage
11539 2012.08.01
2012.08.02
4 6 4 S22E60 0030 CRO DRO reversed polarities

location: S23E58

S1837 2012.08.01       N27E19         plage
S1838 2012.08.02   3 1 S17E77 0030   HSX
S1839 2012.08.02   2 1 S27E69 0010   HRX
S1840 2012.08.02   3 1 N09E28 0000   AXX
S1841 2012.08.02   7 3 N07W42 0020   DRO
Total spot count: 36 79 42
Sunspot number: 126 199 162  (total spot count + 10 * number of spotted regions)
Weighted penumbral SN: 78 136 99  (Sum of total spot count + classification weighting for each AR. Classification weighting: X=0, R=3, A/S=5, H/K=10)
Relative sunspot number (Wolf number): 76 70 89 k * (sunspot number). k = 0.6 for SWPC, k = 0.35 for STAR SDO 2K, k = 0.55 for STAR SDO 1K

Monthly solar cycle data

Month Average measured solar flux International sunspot number (SIDC) Smoothed sunspot number Average ap
(3)
2011.05 95.8 41.6 47.6 (+5.8) 8.94
2011.06 95.8 37.0 53.2 (+5.6) 8.06
2011.07 94.2 43.9 57.2 (+4.0) 8.16
2011.08 101.7 50.6 59.0 (+1.8) 7.26
2011.09 133.8 78.0 59.5 (+0.5) 12.27
2011.10 137.3 88.0 59.9 (+0.4) 8.28
2011.11 153.5 96.7 61.1 (+1.2) 5.55
2011.12 141.3 73.0 63.4 (+2.3) 3.78
2012.01 132.5 58.3 65.5 (+2.1) 7.15
2012.02 106.5 33.1 (67.4 projected, +1.9) 8.81
2012.03 114.7 64.2 (68.1 projected, +0.7) 16.08
2012.04 113.0 55.2 (67.5 projected, -0.6) 10.10
2012.05 121.5 69.0 (65.8 projected, -1.7) 7.06
2012.06 119.6 64.5 (65.0 projected, -0.8) 10.08
2012.07 133.9 66.5 (66.0 projected, +1.0) 14.37
2012.08 138.2 (1) 7.9 (2A) / 122.0 (2B) (68.6 projected, +2.6) (12.25)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder (NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The official SIDC international sunspot number is typically 30-50% lower. 2B) Month average to date.
3) Running average based on the quicklook and definitive Potsdam WDC ap indices. Values in red are based on the definitive international Potsdam WDC ap indices.

This report has been prepared by Jan Alvestad. It is based on analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.

SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
