Recent activity

The geomagnetic field was quiet on January 10. Solar wind speed ranged between 420 and 464 km/s, weakly under the influence of a high speed coronal hole stream associated with CH491.

Solar flux measured at 20h UTC on 2.8 GHz was 128.8 (decreasing 3.2 over the last solar rotation). The planetary A index was 4 (STAR Ap - based on the mean of three hour interval ap indices: 4.3). Three hour interval K indices: 01022111 (planetary), 01032211 (Boulder).

The background x-ray flux is at the class B6 level.

At midnight UTC the visible solar disk had 7 spotted regions (in 2K resolution SDO images).

Region 11391 [N12W26] decayed slowly and was mostly quiet.
Region 11393 [N17W70] was mostly quiet and stable, slow decay was observed.
Region 11394 [N19W10] was quiet and stable.
Region 11395 [N22E35] decayed slowly and quietly.

Spotted regions not reported (or interpreted differently) by NOAA/SWPC:
[S1411] reemerged on January 10. Location at midnight: S20E08
[S1422] emerged in the southeast quadrant on January 10. Location at midnight: S16E22
[S1421] emerged in the southeast quadrant on January 10. Location at midnight: S27E28

Coronal mass ejections (CMEs)

January 8-10: No obviously Earth directed CMEs were observed in LASCO and STEREO imagery.

Coronal holes

Coronal hole history (since October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent coronal hole (CH492) in the southern hemisphere was in an Earth facing position on January 9-10. A recurrent coronal hole (CH493) in the northern hemisphere could rotate into an Earth facing position on January 12.

The above coronal hole map is based on a new method where coronal holes are detected automatically. The method may need some fine tuning, however, it has significant advantages over detecting coronal holes manually. The main improvement is the ability to detect coronal holes at and just beyond the solar limbs. Early results using this method for SDO images over a span of several weeks indicate a good match between coronal holes observed over the visible disk and their extent and position at the east and west limbs. Note that the polar coronal holes are easily detected using the new method, the extent and intensity of both holes are consistent with other data sources.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is poor to fair. Propagation on long distance northeast-southwest paths is poor to fair.

Forecast

The geomagnetic field is expected to be quiet on January 11. Weak effects from CH492 could cause a few unsettled intervals on January 12-13. Quiet conditions are likely on January 14 becoming quiet to unsettled on January 15-16 due to effects from CH493.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)


1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions

Click on image for higher resolution image) Compare to the previous day's image

When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue (blue-green) is positive.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered
detected
Spot count Location at midnight Area Classification SDO / HMI 4K continuum
image with magnetic polarity overlay
Comment
SWPC STAR SDO SWPC STAR Current Previous
11391 2012.01.02 22 24 N12W25 0270 DKI EAI

beta-gamma

area: 0350

11392 2012.01.02
2012.01.03
    N18W82           plage
11393 2012.01.04
2012.01.05
8 10 N17W70 0530 EKI EKO

area: 0700

11394 2012.01.05
2012.01.06
  1 N18W16 0000   AXX location: N19W10
S1411 2012.01.06   3 S20E08 0000   BXO
S1413 2012.01.06     N33W32           plage
11395 2012.01.07
2012.01.08
3 3 N22E35 0180 CAO HSX



S1415 2012.01.07     N12E01           plage
S1417 2012.01.07     S24W55           plage
S1418 2012.01.08     N23W53           plage
S1419 2012.01.08     S22W03         plage
S1420 2012.01.09     N30W15         plage
S1421 2012.01.09     S27E57         plage
S1422 2012.01.10   3 S16E22 0000   AXX
S1423 2012.01.10   2 S27E28 0000   BXO
Total spot count: 33 46
Sunspot number: 63 116  (total spot count + 10 * number of spotted regions)
Weighted penumbral SN: 58 66  (Sum of total spot count + classification weighting for each AR. Classification weighting: X=0, R=3, A/S=5, H/K=10)
Relative sunspot number (Wolf number): 38 52  k * (sunspot number). k = 0.6 for SWPC. k = 0.45 (changed from 0.33 on Nov.1) for STAR SDO

Monthly solar cycle data

Month Average measured solar flux International sunspot number (SIDC) Smoothed sunspot number Average ap
(3)
2008.07 65.7 (SF minimum) 0.5 2.8 (-0.4)
2008.12 69.2 0.8 1.7 (-)
sunspot minimum
3.25
2010.10 81.6 23.5 23.2 (+3.6) 6.07 / 6.27
2010.11 82.5 21.5 26.5 (+3.3) 4.80 / 5.50
2010.12 84.2 14.4 28.8 (+2.3) 3.41 / 4.35
2011.01 83.6 19.1 31.0 (+2.2) 4.32 / 5.51
2011.02 94.6 29.4 33.4 (+2.4) 5.41 / 6.44
2011.03 115.0 56.2 36.9 (+3.5) 7.79 / 8.18
2011.04 112.6 54.4 41.8 (+4.9) 9.71 / 8.83
2011.05 95.8 41.6 47.6 (+5.8) 9.18 / 8.94
2011.06 95.8 37.0 53.2 (+5.6) 8.96 / 8.06
2011.07 94.2 43.9 (57.8 projected, +4.6) 9.14 / 8.16
2011.08 101.7 50.6 (62.0 projected, +4.2) 8.16 / 7.26
2011.09 133.8 78.0 (65.3 projected, +3.3) 12.80 / 12.27
2011.10 137.3 88.0 (68.8 projected, +3.5) 7.52
2011.11 153.5 96.7 (73.2 projected, +4.3) 4.58
2011.12 141.3 73.0 (78.6 projected, +5.5) 3.32
2012.01 136.0 (1) 28.4 (2A) / 88.1 (2B) (84.4 projected, +5.8) (4.51)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder (NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The official SIDC international sunspot number is typically 30-50% lower. 2B) Month average to date.
3) Running average based on the preliminary daily SWPC ap indices. Values in red are based on the official NGDC ap indices.

This report has been prepared by Jan Alvestad. It is based on analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.

SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
