Recent activity

The geomagnetic field was quiet to unsettled on June 17. Solar wind speed ranged between 454 and 567 km/sec under the influence of a weak high speed stream from coronal hole CH102.

Solar flux measured at 20h UTC on 2.8 GHz was 111.3. The planetary A index was 7 (STAR Ap - based on the mean of three hour interval ap indices: 8.1).
Three hour interval K indices: 13222232 (planetary), 22232232 (Boulder).

The background x-ray flux is at the class B2 level.

At midnight there were 4 spotted regions on the visible disk. The solar flare activity level was low. A total of 1 C class event was recorded during the day.

Region 10631 decayed slowly and will rotate to the southwest limb late today.
Region 10632 was quiet and stable.
Region 10634 developed further in the leading spot section with negative polarity spots emerging just south of the large positive polarity penumbra. Slow decay was observed in the trailing spot section. A minor M class flare is possible. Flare: C1.2 at 02:41 UTC.
Region 10635 developed in the trailing spot section and could produce a minor M class flare.

Coronal mass ejections (CMEs)

June 15-17: No fully or partly Earth directed CMEs observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent trans equatorial coronal hole (CH102) was in a geoeffective position on June 14-15.

Processed SOHO/EIT 284 image at 13:05 UTC on June 15. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on June 18-20 with a chance of active intervals on June 18 due to a high speed stream from coronal hole CH102.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor to very poor. Propagation along long distance north-south paths is fair to good. Trans Atlantic propagation conditions are monitored every night on 1470 kHz. Dominant station tonight: Radio Cristal del Uruguay. Radio Vibración (Venezuela) was noted at times. After local sunrise propagation was again best towards Argentina, Uruguay and Brazil. Radio Real (Uruguay) on 1590 kHz had a nice signal. An interesting Spanish speaking station was heard above the dominant Brazilian station on 740 kHz for a few minutes. The only North American station noted was WWZN on 1510 kHz with a weak to occasionally fair signal. WDHP on 1620 had a good signal and Caribbean Beacon on 1610 kHz had a better than usual signal.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10630 2004.06.07     N14W74     plage
10631 2004.06.09 4 2 S10W66 0030 CAO classification was HRX
at midnight, area 0010
10632 2004.06.10 1 1 S12W27 0070 HSX
10633 2004.06.13 1   S08W15 0000 AXX spotless
10634 2004.06.13 28 31 N12E20 0390 FKI beta-gamma
10635 2004.06.14 22 39 S11E38 0440 EKI beta-gamma
Total spot count: 56 73
SSN: 106 113

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.05 115.7 55.2 67.6 (-2.5)
2003.06 129.3 77.4 65.0 (-2.6)
2003.07 127.7 83.3 61.8 (-3.2)
2003.08 122.1 72.7 60.0 (-1.8)
2003.09 112.2 48.7 59.5 (-0.5)
2003.10 151.7 65.5 58.1 (-1.4)
2003.11 140.8 67.3 56.7 (-1.4)
2003.12 114.9 46.5 (54.4 predicted, -2.3)
2004.01 114.1 37.2 (50.5 predicted, -3.9)
2004.02 107.0 46.0 (46.2 predicted, -4.3)
2004.03 112.0 48.9 (43.5 predicted, -2.7)
2004.04 101.2 39.3 (41.4 predicted, -2.1)
2004.05 99.8 41.5 (38.2 predicted, -3.2)
2004.06 92.6 (1) 39.3 (2) (35.3 predicted, -2.9)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
