Recent activity

The geomagnetic field was quiet to unsettled on September 1. Solar wind speed ranged between 453 and 561 km/sec under the weakening influence of a high speed stream from coronal hole CH111.

Solar flux measured at 20h UTC on 2.8 GHz was 89.9. The planetary A index was 9 (STAR Ap - based on the mean of three hour interval ap indices: 10.0).
Three hour interval K indices: 31222333 (planetary), 31223212 (Boulder).

The background x-ray flux is at the class B2 level.

At midnight there was one spotted region on the visible disk. The solar flare activity level was very low. No C class events were recorded during the day.

New region 10667 rotated into view at the southeast limb.

Coronal mass ejections (CMEs)

August 30 - September 1: No obviously Earth directed CMEs were observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent coronal hole (CH112) in the northern hemisphere will likely rotate into a geoeffective position on September 4.

Processed SOHO/EIT 284 image at 01:06 UTC on September 2. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on September 2-6.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation along long distance north-south paths is poor to occasionally fair. Trans Atlantic propagation conditions are monitored every night on 1470 kHz. Dominant station tonight: Radio Cristal del Uruguay with a weak signal. On other frequencies a few stations from Brazil could be heard. From the Caribbean both WDHP on 1620 and Harbour Light on 1400 kHz were noted with weak to fair signals.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10666 2004.08.29     N17W09     plage
10667 2004.09.01 2 2 S09E76 0180 HAX
S449 emerged on
2004.08.30
    S14E11     plage
Total spot count: 2 2
SSN: 12 12

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.07 127.7 83.3 61.8 (-3.2)
2003.08 122.1 72.7 60.1 (-1.7)
2003.09 112.2 48.7 59.6 (-0.5)
2003.10 151.7 65.5 58.2 (-1.4)
2003.11 140.8 67.3 56.8 (-1.4)
2003.12 114.9 46.5 54.8 (-2.0)
2004.01 114.1 37.7 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 (47.0 predicted, -2.3)
2004.04 101.2 39.3 (44.8 predicted, -2.2)
2004.05 99.8 41.5 (41.5 predicted, -3.3)
2004.06 97.4 43.2 (38.6 predicted, -2.9)
2004.07 119.1 51.0 (36.8 predicted, -1.8)
2004.08 109.6 40.9 (35.4 predicted, -1.4)
2004.09 89.9 (1) 0.4 (2) (34.2 predicted, -1.2)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
