Last major update issued on February 24, 2005 at 04:55 UTC.
[Solar and
geomagnetic data - last month (updated daily)]
[Solar wind and
electron fluence charts (updated daily)]
[Solar cycles 21-23
(last update January 2, 2005)]
[Solar cycles 1-20]
[Graphical comparison
of cycles 21, 22 and 23 (last update January 2, 2005)]
[Graphical
comparison of cycles 2, 10, 13, 17, 20 and 23 (last update January
2, 2005)]
[Historical solar and
geomagnetic data charts 1954-2004 (last update February 1, 2005)]
[Archived reports
(last update February 16, 2005)]
The geomagnetic field was quiet on February 23. Solar wind speed ranged between 337 and 505 km/sec. While there was no geomagnetic disturbance, the interplanetary magnetic field was northwards all day and the total field was significantly enhanced compared to normal values.
Solar flux measured at 20h UTC on 2.8 GHz was 84.6. The planetary
A
index was 4 (STAR Ap - based on the mean of three hour interval ap
indices: 4.5).
Three hour interval K indices: 11211211 (planetary), 11211232 (Boulder).
The background x-ray flux is at the class A9 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was low. A total of 2 C class events was recorded during the day.
Region 10735 produced a C flares from behind the southwest limb. Flare: C1.3 at 06:28 UTC.February 21-23: No obvious fully or partly Earth directed CMEs were observed.
Coronal hole
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28
days ago 27 days ago 26 days ago
A poorly defined trans equatorial coronal hole (CH147) was in a geoeffective position on February 20-22. A recurrent coronal hole (CH148) in the northern hemisphere was in a geoeffective position on February 23-24.
Processed SOHO/EIT 284 image at 01:06 UTC on February 24. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on February 24 and quiet to active on February 25-27 due to coronal hole effects.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next
48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair to good. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: WLAM Lewiston ME and WWNN Boca Raton FL. Many stations from North America were heard on other frequencies, particularly stations in the US northeastern states had good signals.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
Active region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
10735 | 2005.02.10 | 1 | S09W97 | 0060 | HSX | rotated out of view | |
10736 | 2005.02.20 | 3 | N13W92 | 0090 | CSO | rotated out of view | |
10737 | 2005.02.23 | 8 | 9 | S07W31 | 0040 | DSI | |
10738 | 2005.02.23 | 2 | S10E10 | 0010 | BXO | spotless | |
S514 | emerged on 2005.02.15 |
S08W48 | plage | ||||
S515 | emerged on 2005.02.17 |
S13W32 | plage | ||||
S516 | emerged on 2005.02.18 |
S07W61 | plage | ||||
Total spot count: | 14 | 9 | |||||
SSN: | 54 | 19 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2003.12 | 114.9 | 46.5 | 54.8 (-1.9) |
2004.01 | 114.1 | 37.3 | 52.0 (-2.8) |
2004.02 | 107.0 | 45.8 | 49.3 (-2.7) |
2004.03 | 112.0 | 49.1 | 47.1 (-2.2) |
2004.04 | 101.2 | 39.3 | 45.5 (-1.6) |
2004.05 | 99.8 | 41.5 | 43.9 (-1.6) |
2004.06 | 97.4 | 43.2 | 41.7 (-2.2) |
2004.07 | 119.1 | 51.0 | 40.3 (-1.4) |
2004.08 | 109.6 | 40.9 | (38.9 predicted, -1.4) |
2004.09 | 103.1 | 27.7 | (36.6 predicted, -2.3) |
2004.10 | 105.9 | 48.4 | (34.4 predicted, -2.2) |
2004.11 | 113.2 | 43.7 | (32.5 predicted, -1.9) |
2004.12 | 94.5 | 17.9 | (30.2 predicted, -2.3) |
2005.01 | 102.2 | 31.3 | (27.6 predicted, -2.6) |
2005.02 | 101.6 (1) | 44.2 (2) | (25.2 predicted, -2.4) |
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC)
sunspot number. The official international sunspot number is typically
30-50% less.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
