Recent activity

The geomagnetic field was inactive to quiet on January 27. Solar wind speed ranged between 332 and 366 km/sec. A weak solar wind disturbance was observed beginning at ACE after 22h UTC, its origin is at this time not obvious.

Solar flux measured at 20h UTC on 2.8 GHz was 86.9. The planetary A index was 3 (STAR Ap - based on the mean of three hour interval ap indices: 3.3).
Three hour interval K indices: 00001211 (planetary), 00111331 (Boulder).

The background x-ray flux is at the class A4 level.

At midnight there were 2 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10723 decayed slowly and was quiet.
Region 10727 decayed fairly quickly and was quiet.

Coronal mass ejections (CMEs)

January 25-27: No obvious fully or partly Earth directed CMEs were observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A coronal hole (CH141) in the southern hemisphere was in a geoeffective position on January 25-26. A recurrent coronal hole in the northern hemisphere (CH142) will be in a geoeffective position on January 27-28.

Processed SOHO/EIT 284 image at 01:06 UTC on January 28. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to active on January 28 and unsettled to active on January 29-February 1 due to high speed streams from CH141 and CH142. Occasional minor storm intervals are possible.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Cristal del Uruguay with a weak signal. On other frequencies a few stations from North America were noted with the best signals from WWZN on 1510 and KNR (Greenland) on 650 kHz.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10723 2005.01.17 1 1 N06W57 0050 HSX area was 0040 at midnight
10726 2005.01.21     S01W54     plage
10727 2005.01.24 10 6 S09W02 0080 DAO area was 0050 at midnight
10728 2005.01.25 2   S14E36 0010 BXO spotless
S495 visible on
2005.01.13

S06W87

plage
S500 visible on
2005.01.18
    N10W47     plage
S504 emerged on
2005.01.24
    S12W36     plage
Total spot count: 13 7
SSN: 43 27

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.11 140.8 67.3 56.7 (-1.5)
2003.12 114.9 46.5 54.8 (-1.9)
2004.01 114.1 37.3 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 47.1 (-2.2)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.9 (-1.6)
2004.06 97.4 43.2 41.7 (-2.2)
2004.07 119.1 51.0 (39.6 predicted, -1.9)
2004.08 109.6 40.9 (38.0 predicted, -1.6)
2004.09 103.1 27.7 (36.1 predicted, -1.9)
2004.10 105.9 48.4 (33.9 predicted, -2.2)
2004.11 113.2 43.7 (32.0 predicted, -1.9)
2004.12 94.5 17.9 (29.7 predicted, -2.3)
2005.01 104.7 (1) 46.8 (2) (27.0 predicted, -2.7)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
