Recent activity

The geomagnetic field was unsettled to minor storm on December 7. Solar wind speed ranged between 561 and 761 km/s (all day average 647 km/s - increasing 151 km/s over the previous day) under the influence of a high speed stream from CH250 during the first half of the day. After 11h UTC there is some evidence of the presence of a non coronal hole related component in the solar wind. From 11:11 to 11:14 UTC solar wind speed increased by more than 100 km/sec. Additionally there was a fairly rapid increase in the proton levels as observed by ACE just before this time. The change in solar wind data could be explained by the insertion of a high speed component from the CME associated with the X9 flare on December 5.

The interplanetary magnetic field suddenly became much stronger and had strong southward excursions after 04h UTC on December 8. This is likely the arrival of the CME associated with the X6.5 flare on December 6.

Solar flux measured at 18h UTC on 2.8 GHz was 95.8. The planetary A index was 25 (STAR Ap - based on the mean of three hour interval ap indices: 25.0). Three hour interval K indices: 54544333 (planetary), 44443333 (Boulder).

The background x-ray flux is at the class B2 level.

At midnight there were 2 spotted regions on the visible solar disk. The solar flare activity level was moderate. A total of 5 C and 1 M class events was recorded during the day.

Region 10927 was quiet and stable.
Region 10930 has lost much of its complexity after the X6.5 flare on December 6. That flare appears to have destroyed the magnetic delta structure that was a key factor for the production of the huge flares. M flares are still possible and there is a small chance of an addiotnal X class flare. Flares: C1.9 at 00:34, C2.0 at 03:36, C6.1/1F at 04:45, C1.1 at 11:48, C1.2 at 15:15 and M2.0/1N at 19:13 UTC.

Coronal mass ejections (CMEs)

December 5: While no LASCO images are available from the time after the X9 event, such events are often associated with large and fast CMEs, so there is at least a chance of a flank impact from the CME produced by the event.
December 6:
No LASCO images available. It is likely that a large and fast CME was produced by the extremely bright X6.5 flare. This CME could reach Earth on December 8.
December 7: No obvious partly or fully Earth directed CMEs were detected in very incomplete LASCO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently in or approaching Earth facing positions.

Processed SOHO/EIT 284 image at 19:06 UTC on November 24. The darkest areas on the solar disk are likely coronal holes.


The geomagnetic field is expected to be unsettled to major storm on December 8 due to CME effects and quiet to active on December 9-10.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.


Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor to useless. Propagation on long distance northeast-southwest paths is very poor.

Monitoring remarks from a location near N58E06: The only audio noted from a trans Atlantic station was on 1480 kHz where I heard a weak unidentified signal.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
Location at midnight Area Classification Comment
10926 2006.11.24 2   S08W82 0020 BXO rotated out of view
10927 2006.11.27 2 1 N07W76 0070 HSX
10929 2006.12.04     N03E28     plage
10930 2006.12.04 14 10 S06E45 0430 DKI beta-gamma
Total spot count: 18 11
SSN: 48 31

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2005.09 91.1 21.9 25.8 (-1.6)
2005.10 77.0 8.7 25.5 (-0.3)
2005.11 86.3 18.0 24.9 (-0.6)
2005.12 90.7 41.1 23.0 (-1.9)
2006.01 83.4 15.3 20.8 (-2.2)
2006.02 76.5 4.9 18.6 (-2.2)
2006.03 75.4 10.6 17.3 (-1.3)
2006.04 89.0 30.2 17.1 (-0.2)
2006.05 80.9 22.2 17.3 (+0.2)
2006.06 76.5 13.9 (16.3 predicted, -1.0)
2006.07 75.7 12.2 (14.7 predicted, -1.6)
2006.08 79.0 12.9 (14.2 predicted, -0.5)
2006.09 77.8 14.5 (14.1 predicted, -0.1)
2006.10 74.3 10.4 (13.0 predicted, -1.1)
2006.11 86.3 21.5 (11.5 predicted, -1.5)
2006.12 93.7 (1) 11.4 (2) (11.3 predicted, -0.2)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
