The geomagnetic field was quiet to active on July 20. Solar wind speed ranged between 299 and 533 km/s (average speed was 389 km/s, increasing 55 km/s over the previous day). The high speed stream associated with CH278 was observed arriving at ACE just after 05h UTC.
Solar flux measured at 20h UTC on 2.8 GHz was 67.3. The planetary A index was 12 (STAR Ap - based on the mean of three hour interval ap indices: 12.3). Three hour interval K indices: 01334322 (planetary), 01434322 (Boulder).
The background x-ray flux is below the class A1 level.
At midnight the visible solar disk was spotless. The solar flare activity level was very low. No C class events were recorded during the day.
July 18-20: No obvious fully or partly Earth directed CMEs were observed.
Coronal hole
history (since late October 2002)
Compare today's report to the situation one solar rotation ago:
28
days ago
27
days ago
26
days ago
A recurrent coronal hole (CH278) in the southeastern quadrant was in a geoeffective position on July 15-16. A trans equatorial recurrent coronal hole (CH279) will likely rotate into an Earth facing position on July 22-23.
.
Processed STEREO 195 image at 21:45 UTC on July 20. The darkest areas on the solar disk are likely coronal holes.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is fair to good.
Monitoring remarks from a location near N58E06: July 21: Many stations from Argentina, Brazil and Uruguay were heard until about 10 minutes after LSR when signals disappeared fairly quickly. 1430, 1470, 1510 and 1540 kHz all had at least 2 stations at times.
The geomagnetic field is expected to be quiet to unsettled on July 21, perhaps with a few active intervals due to effects from CH278. Quiet conditions are likely on July 22-24. A high speed stream from CH279 could arrive on July 25 and cause unsettled to minor storm conditions that day and on July 26.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the
color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96
hours.
3) There is a possibility of either M or X class flares within the next
48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
Active region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
Total spot count: | 0 | 0 | |||||
SSN: | 0 | 0 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2006.05 | 80.9 | 22.3 | 17.3 (+0.2) |
2006.06 | 76.5 | 13.9 | 16.3 (-1.0) |
2006.07 | 75.7 | 12.2 | 15.3 (-1.0) |
2006.08 | 79.0 | 12.9 | 15.6 (+0.3) |
2006.09 | 77.8 | 14.4 | 15.6 (+0.0) |
2006.10 | 74.3 | 10.4 | 14.2 (-1.4) |
2006.11 | 86.3 | 21.5 | 12.7 (-1.5) |
2006.12 | 84.5 | 13.6 | 12.1 (-0.6) |
2007.01 | 83.3 | 16.9 | (11.9 predicted, -0.2) |
2007.02 | 77.7 | 10.6 | (11.3 predicted, -0.6) |
2007.03 | 72.2 | 4.8 | (10.8 predicted, -0.5) |
2007.04 | 72.4 | 3.7 | (10.8 predicted, unchanged) |
2007.05 | 74.4 | 11.7 | (10.6 predicted, -0.2) |
2007.06 | 73.7 | 12.0 | (10.7 predicted, +0.1) |
2007.07 | 73.6 (1) | 14.0 (2) | (11.0 predicted, +0.3) |
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC)
sunspot number. The official international sunspot number is typically
30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
