Solar Terrestrial Activity Report

Last major update issued on September 24, 2004 at 03:05 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update September 2, 2004)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update September 2, 2004)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update September 2, 2004)]
[Historical solar and geomagnetic data charts 1954-2004 (last update August 28, 2004)]
[Archived reports (last update September 11, 2004)]

Recent activity

The geomagnetic field was quiet to active on September 23. Solar wind speed ranged between 425 and 458 km/sec.

Solar flux measured at 20h UTC on 2.8 GHz was 90.2. The planetary A index was 12 (STAR Ap - based on the mean of three hour interval ap indices: 14.3).
Three hour interval K indices: 44222222 (planetary), 44222222 (Boulder).

The background x-ray flux is at the class A9 level.

At midnight there was 1 spotted region on the visible disk. The solar flare activity level was low. A total of 1 C class event was recorded during the day. That was a C1.4 flare at 08:00 with an origin behind the northwest limb.

Region 10673 decayed slowly and quietly.

Coronal mass ejections (CMEs)

September 21-23: NO CMEs observed in limited LASCO data set.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently approaching geoeffective positions.

Processed SOHO/EIT 284 image at 19:06 UTC on September 10. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on September 25-27. A recurrent coronal hole flow could arrive on September 27, however, currently available images do not indicate the presence of a coronal hole.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are monitored every night on 1470 kHz. Dominant station tonight: Radio Vibración (Venezuela) with a weak signal. The best signal was noted from Harbour Light on 1400 kHz, otherwise a few of the most common Newfoundland and east coast US stations were heard with weak signals.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10673 2004.09.15 9 4 S13W31 0240 DSO
10674 2004.09.20     S10W62     plage
Total spot count: 9 4
SSN: 19 14

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2003.07 127.7 83.3 61.8 (-3.2)
2003.08 122.1 72.7 60.1 (-1.7)
2003.09 112.2 48.7 59.6 (-0.5)
2003.10 151.7 65.5 58.2 (-1.4)
2003.11 140.8 67.3 56.8 (-1.4)
2003.12 114.9 46.5 54.8 (-2.0)
2004.01 114.1 37.7 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 (47.0 predicted, -2.3)
2004.04 101.2 39.3 (44.8 predicted, -2.2)
2004.05 99.8 41.5 (41.5 predicted, -3.3)
2004.06 97.4 43.2 (38.6 predicted, -2.9)
2004.07 119.1 51.0 (36.8 predicted, -1.8)
2004.08 109.6 40.9 (35.4 predicted, -1.4)
2004.09 107.2 (1) 44.6 (2) (34.2 predicted, -1.2)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
