Recent activity

The geomagnetic field was unsettled to minor storm on March 8. Solar wind speed ranged between 622 and 845 km/sec under the influence of a high speed stream from CH149.

Solar flux measured at 20h UTC on 2.8 GHz was 93.5. The planetary A index was 26 (STAR Ap - based on the mean of three hour interval ap indices: 26.5).
Three hour interval K indices: 45533334 (planetary), 45433334 (Boulder).

The background x-ray flux is at the class B2 level.

At midnight there were 3 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10741 lost the trailing spots, however, several small spots emerged in the leading spot section.
Region 10742 added spots and penumbral area. The region has a significant amount of polarity intermixing and further growth will increase the chances of minor M class flares occurring.

Spotted regions not numbered by NOAA/SEC:
[S523] This region emerged near the southwest limb on March 7 and somewhat to the southwest of the position of spotless region 10739. SEC and USAF chose to reuse the old region number. Location at midnight: S07W79.

Coronal mass ejections (CMEs)

March 6-8: No obvious fully or partly Earth directed CMEs were observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A large recurrent coronal hole (CH149) in the northern hemisphere was in a geoeffective position on March 3-7.

Processed SOHO/EIT 284 image at 13:06 UTC on March 8. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be unsettled to minor storm on March 9 and quiet to active on March 10 due to a high speed stream from CH149. Quiet to unsettled is likely on March 11-12.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation along long distance north-south paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Vibración (Venezuela) with a weak signal. The only North American stations noted were CJYQ 930 with a fair signal and WWZN 1510 kHz with a weak signal.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10739 2005.02.26 3   S07W81 0040 AXX spotless, this is new region S523. Actual location: S03W81
10741 2005.03.04 8 10 N14E17 0040 CAO
10742 2005.03.07 11 15 S06E56 0080 BXO beta-gamma
classification was DAI at midnight, area 0110
S523 emerged on
2005.03.07
  2 S07W79 0040 DSO
Total spot count: 22 27
SSN: 52 57

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2004.01 114.1 37.3 52.0 (-2.8)
2004.02 107.0 45.8 49.3 (-2.7)
2004.03 112.0 49.1 47.1 (-2.2)
2004.04 101.2 39.3 45.5 (-1.6)
2004.05 99.8 41.5 43.9 (-1.6)
2004.06 97.4 43.2 41.7 (-2.2)
2004.07 119.1 51.0 40.3 (-1.4)
2004.08 109.6 40.9 39.2 (-1.1)
2004.09 103.1 27.7 (37.4 predicted, -1.8)
2004.10 105.9 48.4 (35.2 predicted, -2.2)
2004.11 113.2 43.7 (33.3 predicted, -1.9)
2004.12 94.5 17.9 (31.0 predicted, -2.3)
2005.01 102.2 31.3 (28.3 predicted, -2.7)
2005.02 97.2 29.1 (25.9 predicted, -2.4)
2005.03 81.2 (1) 6.4 (2) (24.1 predicted, -1.8)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
